PNF18-6LFW
PNF18-6LF
PNF18-8LF
PNF18-10LF
STUD
SIZE
#6
#6
#8
#10
DIMENSIONS - in.
W
C
M
.01
.02
.03
.29
.20
.63
(7.4)
(5.1)
(16.0)
.27
.20
.63
(6.9)
(5.1)
(16.0)
.29
.26
.68
(7.4)
(6.6)
(17.3)
.33
.25
.68
(8.4)
(6.4)
(17.3)
TOOLS
CT-100A
*CT-160
*CT-260
**CT-400
CT-600-A (CT-500CH)
CT-600-A (CT-550CH)
CT-1550
CT-1551
CT-2500 (CT-2550CH)
1
THIS COPY IS PROVIDED ON A RESTRICTED BASIS AND IS NOT TO BE USED IN ANY WAY DETRIMENTAL TO THE INTERESTS OF PANDUIT CORP.
A
.03
.85
(21.6)
.82
(20.8)
.89
(22.6)
.89
(22.6)
H
.01
.15
(3.8)
.15
(3.8)
.16
(4.1)
.19
(4.8)
W
H DIA
TERMINAL
B
** UL LISTED ONLY
*PANDUIT APPROVED TOOL
C RAD
NOTES:
1. UL LISTED AND CSA CERTIFIED FOR:
A. 600V MAX. BLDG WIRE
1000V MAX. IN SIGNS, FIXTURES & LUMINARIES
B. 221 F (105 C) MAX TEMP. RATING
C. #22-18 AWG SOLID OR STRANDED, COPPER WIRE
2. SEE WWW.PANDUIT.COM FOR PACKAGE QUANTITIES
3. MATERIAL:
A. STAMPING - .032" [.81]THK COPPER, TIN PLATED
B. HOUSING - NYLON, RED
C. SLEEVE - BRASS, TIN PLATED
4. DIMENSIONS IN BRACKETS ARE IN MILLIMETERS
5. WIRE STRIP LENGTH:
7/32 + 1/32 (5.6 + .8)
- 0
- 0
LISTED
587H
E52164
CERTIFIED
LR31212
