353648-9: DescriptionCONNECTOR, 120 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, SURFACE MOUNT, RECEPTACLE; CategoryThe connector The connector; File Size115KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

353648-9 Overview

CONNECTOR, 120 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, SURFACE MOUNT, RECEPTACLE

353648-9 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Other features	POLARIZED
Body/casing type	RECEPTACLE
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD (8)
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	353648
Plug information	353651-9
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	0.5 mm
Termination type	SURFACE MOUNT
Total number of contacts	120
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Product Feature Selector

> Product Details

353648-9 Product Details

Live Product Chat

Product Photo

0.5mm Free Height

5 of 6 EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

View Mating Products (3)

Product Feature Selector

C ontact Us About This Product

353648-9

T E I nternal N umber: 3 5 3 6 4 8 - 9

Product Highlights:

Receptacle

Family Name = Free Height

.50 mm C enterline

Number of Positions = 120

In-Line C ontact Layout

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

REPRESENTATIVE TERMINALS AND C ONNEC TORS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Gender

= Receptacle

Number of Positions

= 120

PC B Mount Angle = Vertical

Keyed

= Yes

Industry Application = Board-to-Board (Personal

Systems/C omputers)

Body Related Features:

C enterline (mm [in])

= 0.50 [0.0197]

Board-to-Board Stack Height (mm [in])

= 4.00 [0.157], 7.00 [0.276],

8.00 [0.315]

Grounding C ontact

= With

Locating Post(s)

= With

Vacuum C over

= With

Type = C OM Express

Contact Related Features:

Family Name = Free Height

C ontact Layout

= In-Line

C ontact Base Material = C opper Alloy

C ontact Mating Area Plating Material

= Gold (8)

Region = Asia/Pacific

Industry Standards:

RoHS/ELV C ompliance

= ELV compliant, 5 of 6 C ompliant

Lead Free Solder Processes

= Reflow solder capable to 245?C

Packaging Related Features:

Packaging Method

= Tape & Reel

Other:

Brand = AMP
