SMT CURRENT SENSE
TRANSFORMERS
PE-68XXXNL Series
Height:
7.1mm Max
Footprint:
14.6mm x 12.6mm Max
Current Rating:
up to 15A
Frequency Range:
50kHz to 500kHz
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
Part
5,6
Number
PE-68210NL
PE-68280NL
PE-68383NL
Turns
Ratio
1:1:50
1:1:100
1:1:200
Current
2
Rating
(A)
15
15
15
Secondary
Inductance
(mH MIN)
3.8
14.8
59.2
DCR
(mΩ MAX)
Primary
(1,3-2,4)
1.15
1.15
1.15
Secondary
(5-6)
380
930
3900
Hipot
(V
RMS
)
500
500
500
NOTES:
1. The temperature of the component (ambient temperature plus temper-
ature rise) must be within the specified operating temperature range.
2.The maximum current rating is based upon temperature rise of the
component and represents the dc current which will cause a typical
temperature rise of 40°C with no air flow when both one turn windings
connected in parallel.
3. To calculate the value of the terminating resistor (Rt) use the following
formula: Rt (Ω) = V
REF
* N / (Ipeak_primary)
4. The peak flux density of the device must remain below 2000 Gauss.
To calculate the peak flux density for a uni-polar current use the
following formula:
B
PK
= 14.29 * V
REF
* (Duty_Cycle_Max) * 10
5
/ ( N * Freq_kHz)
* for bi-polar current applications divide B
PK
as calculated above by 2.
5. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to
the part number (i.e. PE-68210NL becomes PE-68210NLT). Pulse complies
to industry standard tape and reel specification EIA481.
6. The "NL" suffix indicates an RoHS-compliant part number. Non-NL suffixed
parts are not necessarily RoHS compliant, but are electrically and mechani-
cally equivalent to NL versions. If a part number does not have the "NL"
suffix, but an RoHS compliant version is required, please contact Pulse for
availability.
Mechanical
2X
.100
2,54
2X
.030
0,76
Schematic
1
5
1 TURN
2
3
1
5
2
R
.500
12,70
.400
10,16
N
S
TURNS
6
1 TURN
4
.490 ± .015
12,45 ±
0,38
R
Iprimary
4x
.040
1,02
4x
.100
2,54
Isecondary
1
N
Vref
3
6
4
.410
10,41
SUGGESTED PAD LAYOUT
RT
APPLICATION CIRCUIT
.280 MAX
7,11
.410 ± .015
10,41 ±
0,38
.495 MAX
12,57
.575 MAX
14,61
.005/0,13
6 SURFACES
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
111
SPM2007 (11/07)
