V18
︳
Features
*Universal Input Range 90-264VAC
* Meets EN55022 Class “B” and
CISPR/FCC Class B, Conducted
* Continuous Short Circuit Protection
* Leakage Current 0.25mA Max.
* Over Voltage Protection
* Meet CoC V5 Tier 2 & DoE Level VI
* (Output cable length
≦
1800mm)
(TRG36A09: Output Cable Length
≦
1220mm)
(TRG36A05: Output Cable Length
≦
720mm
18AWG/UL2464)
* No Load Power Consumption<75mW
TRG36 SERIES
36W SWITCHING
ADAPTER
Ordering information
TRG36AXX-
Model No.
XX
DC Plug Type
E
With OVP
XX
DC Cable Length and Type
01: 720mm
02: 1220mm
03: 1800mm
11: 720mm with Ferrite Core
12:1220mm with Ferrite Core
13:1800mm with Ferrite Core
*18AWG/UL1185
RIPPLE &
OUTPUT
MODEL
VOLTAGE
TRG36A05
TRG36A09
TRG36A12
TRG36A13
TRG36A15
TRG36A18
TRG36A24
TRG36A48
5V
9V
12V
13.5V
15V
18V
24V
48V
CURRENT
NOTE 1
4.0A
3.0A
2.5A
2.4A
2.4A
2.0A
1.5A
0.75A
1%
1%
1%
1%
1%
1%
1%
1%
OUTPUT
NOISE
VOLTAGE
REGULATION
NOTE 2
±2%
±2%
±2%
±2%
±2%
±2%
±2%
±2%
LINE
REGULATION
NOTE 3
±1%
±1%
±1%
±1%
±1%
±1%
±1%
±1%
LOAD
AVG.
REGULATION
EFF.
NOTE 4
±6%
±5%
±5%
±5%
±3%
±2%
±2%
±2%
83.69%
87.30%
87.70%
87.97%
88.31%
88.31%
88.31%
88.31%
Specifications are subject to change without notice.
1
V18
Specifications
INPUT SPECIFICATIONS:
Voltage …....………........…........................................... 90~264Vac
Frequency ………………………………………….……………..... 50 to 60Hz
Inrush Current ………………….………….................... 60A max. @240Vac
Leakage Current …………………………………………….…… 0.25mA max.
TRG36 Series Derating Curve
100%
Rated Load(%)
80%
60%
40%
20%
0%
-20
-10
0
10 20 30
40
o
Ambient Temperature( C)
50
60
20LFM(Natural Convection)
OUTPUT SPECIFICATIONS:
Hold-up Time ……………………………………………… 8ms typ. @115Vac
Short Circuit Protection …………….…………… Continuous(Auto Recover)
Over Voltage Protection …………………………..TVS Component to Clamp
Temperature Coefficient …………………….................................. ±0.05%/℃
GENERAL SPECIFICATIONS:
Isolation …………………………………………… Input to output = 4,242VDC
Operating Temperature ................................ -20 ~ 60℃(see derating curve)
Storage Temperature ………………………………..........……........ -20~85℃
Humidity .................................................... 93% RH max. Non condensing
Cooling …………………………………………………..... Natural Convection
Switching Frequency ……….……………………………….……. 67KHz typ.
MTBF ….…… MIL-HDBK-217F, GB, at 25℃/115VAC ……. 200Khrs min.
Altitude ……………………..……………………………….…………… 2000m
Dimensions …….….. 4.331x2.008x0.886 inches (110.00x51.00x22.50mm)
Weight ……………………………………………………… 190g(0.42 Pounds)
AC Inlet …………………………………………………………….. IEC320/C8
NOTE:
1. Add a 0.1uF ceramic capacitor and a 10uF E.L. capacitor to output for
Ripple & Noise measurement @20MHz BW.
2. Voltage setpoint at 60% load.
3. Line regulation is measured from 100Vac to 240Vac full load.
4. Load regulation measured from 60% to 100% full load and from 60%
to 20% load (60% +/- 40% full load).
SAFETY AND EMC:
Emission and Immunity ………...…. EN55022 Class B, FCC Part 15 Class B
EN61000-6-3, EN61000-3-2, EN61000-3-3
EN55024, EN61204-3, EN61000-6-1
Safety …………………………Class II, IEC60950-1, EN60950-1, UL60950-1
Mechanical Specification
All Dimensions are in inches(mm)
Tolerance:Inches:X.XXX±0.02
Millimeters:X.XX±0.5
4.331[110.00]
70.866[1800.00]±1.969[50.00]
2.008[51.00]
IEC320/C8
DC Plug type: V+ ─●)─ V-
DC Plug:Right Angle(ψ5.5／ψ2.5 )L12mm
18AWG／1800mm
0.886[22.50]
Typical at 25˚C, nominal line and 75% load, unless otherwise Specified
