9 VOLT STRAPS & CONNECTORS
PROTECTIVE BATTERY CAP
•
Protects 9 Volt batteries and battery packs when they are not in use
•
Snap-fits onto battery contacts
•
Both male and female contacts are covered, minimizing physical damage
which can occur during battery handling, shipping and storage
•
Shields the battery contacts and reduces the potential of a short circuit
between battery poles
•
Protects sensitive electronic equipment, systems and circuits, cap prevents
unwanted electrical discharges
•
Protects the battery contacts from damage due to dust, dirt and
contamination
MATERIAL:
Impact Resistant Polypropylene, Black
SHIELDED 9 VOLT BATTERY STRAPS
•
Insulates and shields 9 Volt battery
snap-on connector contacts
•
Assures safe secure use, reduces the
potential of short circuits and prevents
tampering with battery contacts
•
Protects circuits, prevents unwanted
electrical discharge due to unintended
grounding
•
Protects battery contacts from dust, dirt,
and physical damage
•
Ideal for rugged applications, made of
high impact molded plastic with integral
wire lead strain relief
SPECIFICATIONS
Base:
Polypropylene
Male/Female Contacts:
Brass, Nickel Plate
Wires (Red & Black):
#26AWG, Tinned,
.187 end strip, UL/CSA1007
Y
CAT.
NO.
84-4
84-6
84-8
*LEAD
LENGTH
4.00
6.00
8.00
I
-STYLE
CAT.
NO.
81-4
81-6
81-8
*LEAD
LENGTH
4.00
6.00
8.00
CAT. NO. 96
T
-STYLE
with Strain Relief
BATTERY SNAP-ONS
(Miniature and Standard)
*Tolerance on lead length +/-.250
*Tolerance on lead length +/-.250
VERTICAL 9 VOLT PC SNAP-ONS
•
Space saving, economical
•
Excellent mechanical strength
•
Low contact resistance
•
Durable fibre base
•
Wave solderable
•
Anti-Wicking Design
For most electronic applications requiring a quick connect and disconnect of
circuit. Commonly used with 9 Volt or other batteries designed with snap
fasteners. Ideal for temporary or permanent means of connecting without
soldering. Can be cascaded together for multiple connections.
DIMENSIONS FOR REFERENCE ONLY
FIG. 1
FIG. 3
FIG. 5
Stud only
Stud w/Crimp Lugon
on Phenolic Washer
FIG. 2
SPECIFICATIONS
Base:
.062 Fibre
Contacts:
Steel, Nickel Plate
Pins:
Brass, Tin Plate
FIG. 4
FIG. 6
Mounting Detail
CAT. NO. 968
-
With PC Pins
•
Cost saving design
•
Ideal for custom applications
Attach your own terminals and wire leads
•
CAT.
NO.
261
262
269
270
263
264
271
272
265
266
273
274
Socket only
Socket w/Crimp Lugon
on Phenolic Washer
SPECIFICATIONS
Base:
.062 Fibre
Contacts:
Steel, Nickel Plate
CAT. NO. 68
-
Without PC Pins
FIG.
NO.
1
1
2
2
3
3
4
4
5
6
5
6
A
.225
.283
.205
.265
.225
.283
.205
.265
.225
.205
.283
.265
B
.135
.143
.156
.156
.170
.185
.200
.185
.205
.205
.200
.225
C
.312
.425
—
—
.790
.840
.790
.835
.500
.500
.500
.500
Jr.
Sr.
Jr.
Sr.
Jr.
Sr.
Jr.
Sr.
Jr.
Jr.
Sr.
Sr.
DESCRIPTION
Stud only-.093 hole
Stud only-.125 hole
Socket only-.093 hole
Socket only-.125 hole
Stud w/ Lug
Stud w/ Lug
Socket w/ Lug
Socket w/ Lug
Stud on Phenolic Washer
Socket on Phenolic Washer
Stud on Phenolic Washer
Socket on Phenolic
22
31-07 20th Road
•
Astoria, New York 11105-2017
•
(718) 956-8900
•
FAX (718) 956-9040
e-mail: kec@keyelco.com
•
WebSite: keyelco.com
