JFS Series
Single Output Industrial Power Supplies
Features
u
Power factor Corrected
u
Wide range output adjustment
u
Single wire current share
u
Input transient protection
u
UL508 Industrial Controls Approval
u
Factory Mutual Approval (Class 1, Div 2)
u
5 Year Warranty
u
EN61000-4 Input Transient
Specifications
Model
AC Input Voltage
DC Input Voltage Range
Input Current (typ@110VAC)
Inrush Current (110 / 220VAC)
Efficiency (typ@110VAC)
Power Factor
Overcurrent Protection
Overvoltage Protection
Hold Up Time (Typ)
Transient Reponse
Remote Sense
Remote Adjust
Remote On / Off
Signals & Indicators
Parallel Connection
Operating Temperature
Storage Temperature
Humidity (non condensing)
Cooling
Withstand Voltage
Vibration
Shock
Safety Agency Approvals
Conducted & Radiated EMI
Weight (Net / Shipping)
Size (WxHxD)
Warranty
JFS0500
-
-
A rms
A
%
-
-
V
ms
-
-
-
-
-
-
°C
°C
%RH
-
-
-
-
-
-
lbs
mm
-
JFS0750
JFS1000
JFS1500
JFS2000
85-265VAC (170-265VAC JFS2000), 47-63Hz
120-330VDC (240-330VDC for JFS2000)
6
9
12
20
12
(1)
35 / 70
- / 70
75
82
(2)
Meets EN61000-3-2 (0.99 typical)
<110% (auto recovery)
24V models set at 30V, 48V models set at 60V (auto recovery)
16
For 25% load change, recovers to regulation within 5ms
Compenstates for 0.25V drop per leg
With either external Resistor or Voltage
Low = OFF, Open = ON
Open Collector AC Fail and DC Good, Green LED
Single wire current share
-20 to +70°C, derate linearly to 50% load from 50°C (30 min warm up at -20°C)
-40 to +85
10 - 90
Internal fan
Input - Ground 2kVAC, Input - Output 3kVAC, Output - Ground 500VDC
Per IEC68-2-6
Per IEC68-2-27
UL508, UL60950, CSA22.2 No.60950, EN60950, FM3611 & CE Mark
EN55022 Class A, FCC Docket 20780 Part 15, subpartJ, Class A
6/7
7/8
9 / 10
See output line drawings
5 years
Notes: (Consult Installation Manual for detailed specifications, test methods and application notes)
(1) At 220VAC
(2) At 170VAC
OBSOLETE
1-800-526-2324 • www.us.tdk-lambda.com/lp/
1
Disclaimer: us.tdk-lambda.com/lp/legal.htm
JFS Series
Output Ratings
Model
JFS0500-24
JFS0750-24
JFS1000-24
JFS1500-24
JFS2000-24
JFS0500-48
JFS0750-48
JFS1000-48
JFS1500-48
JFS2000-48
Nom.
Volt.
24V
24V
24V
24V
24V
48V
48V
48V
48V
48V
Adjust.
Range
20 - 29
20 - 29
20 - 29
20 - 29
20 - 29
36 - 56
36 - 56
36 - 56
36 - 56
36 - 56
Min
Load
0
0
0
0
0
0
0
0
0
0
Max
Current
20.8
31.2
41.6
62.5
83.3
10.4
15.6
20.8
31.2
41.6
Load
Reg
(mV)
< 240
< 240
< 240
< 240
< 240
< 480
< 480
< 480
< 480
< 480
Line
Reg
(mV)
< 240
< 240
< 240
< 240
< 240
< 480
< 480
< 480
< 480
< 480
Ripple
& Noise
(mV p-p)
250
250
250
250
250
500
500
500
500
500
4.87
(123.6)
JFS0500 Outline Drawing
FRONT VIEW
JFS0750/1000 Outline Drawing
SIDE VIEW
11.06
(280.9)
12.13
(308.1)
2.00
(50.8)
FRONT VIEW
12.74
(323.5)
11.74
(298.1)
NOTE:
1. DIMENSIONS ARE IN INCHES EXCEPT DIMENSIONS ( ) ARE IN MM.
2. WEIGHT: NET 6.0 LBS, SHIPPING 7.0 LBS.
4.87
(123.6)
PRELIMINARY
JFS1500/2000 Outline Drawing
SIDE VIEW
3.30
(83.8)
FRONT VIEW
BOTTOM VIEW
12.74
(323.5)
NOTE:
1. DIMENSIONS ARE IN INCHES EXCEPT DIMENSIONS ( ) ARE IN MM.
2. WEIGHT: NET 7.0 LBS, SHIPPING 8.0 LBS.
4.87
(123.8)
Other Industrial Products
SIDE VIEW
HWS
LZS, LZSa
DLP, DPP, DSP
15W to 1500W Single Output
250W to 1500W Single Output
10 to 480W DIN Rail Single Output
5.55
(140.0)
For Additional Information, please visit
us.tdk-lambda.com/lp/products/jfs-series.htm
11.74
(298.1)
BOTTOM VIEW
NOTE:
1. DIMENSIONS ARE IN INCHES EXCEPT DIMENSIONS ( ) ARE IN MM.
2. WEIGHT: NET 9.0 LBS, SHIPPING 10.0 LBS.
1-800-526-2324 • www.us.tdk-lambda.com/lp/
2
Revision A7: Feb 2012
