Information Technology Equipment - General Requirments for Safety (CB Scheme)
Information Technology Equipment - General Requirments for Safety
EAC
RoHs2+
Report / File Number
E224736-A31
E224736-A32
RU-AT.49.09571
Standard
IEC60950-1, 2nd Edition, 2013
EN60950-1, 2nd Endition, 2013
UL60950-1, 2nd Edition, 2014
C22.2 No. 60950-1-07, 2nd Edition, 2014
TP TC 004/2011
RoHS 2011/65/EU + AM2015/863
EMC Compliance
Electromagnetic Compatibility of Multimedia Equipment - Emission Requirements
Condition
without external filter
with external filter
Standard / Criterion
EN55032, Class A
EN55032, Class B
EMC Filtering Suggestions according to EN55032 Class B
C2
L1
+Vin
C1
DC
DC
+Vout
Component List Class B
MODEL
RI3-05xxS
RI3-12xxS
RI3-15xxS
RI3-24xxS
C1
4.7µF
4.7µF
2.2µF
C2
470pF/4kV
470pF/4kV
470pF/4kV
L1
10µH Choke
10µH Choke
10µH, Choke
-Vin
-Vout
www.recom-power.com
REV.: 2/2018
ECO-4
RI3
DC/DC Converter
Specifications
(measured @ Ta= 25°C, nom. Vin, full load and after warm-up unless otherwise stated)
DIMENSION and PHYSICAL CHARACTERISTICS
Parameter
Material
Package Dimension (LxWxH)
Package Weight
Series
Type
case
potting
Value
non conductive plastic, (UL94 V-0)
silicone, (UL94 V-0)
11.5 x 10.2 x 7.6mm
2.2g typ.
Dimension Drawing (mm)
Pin Connections
Pin #
Function
1
-Vin
2
+Vin
3
-Vout
4
+Vout
Tolerance: xx.x= ±0.5mm
xx.xx= ±0.35mm
Pin pitch:
±0.25mm
embossed logo
11.5
7.6
10.2
0.51
Marking
solder pad for /H3 models
4.10
2.54
1.27
1 2 3 4
Bottom View
1 2 3 4
2.54
2.54
Top View
2.54
2.00
7.62
Recommended Footprint
Standard H2 Version
1.00 Ø +0.15/-0
Recommended Footprint
Standard H3 Version
0.85Ø +0.15/-0
0.85Ø
1 2 3 4
Top View
PACKAGING INFORMATION
Packaging Dimension (LxWxH)
Packaging Quantity
Storage Temperature Range
tube
520.0 x 9.3 x 16.5mm
42pcs
-55°C to +125°C
The product information and specifications may be subject to changes even without prior written notice.The product has been designed for various applications; its suitability lies in the responsibility of each customer. The
products are not authorized for use in safety-critical applications without RECOM’s explicit written consent. A safety-critical application is an application where a failure may reasonably be expected to endanger or cause
loss of life, inflict bodily harm or damage property. The applicant shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorized
use of RECOM products in such safety-critical applications.
