PW182RA
PoE Gigabit
• 10/100/1000 (MbPS) Data Rates
• 100-240VAC Universal Input
• Self-contained Injector
• Desktop Style / Non-vented Case
• Power On LED
• UNH IOL Test Report
Universal 19 Watt (IEEE802.3af Non-Compliant)
• Over Load Shutdown and Short Circuit Protection
• Regulated Output With Low Ripple
• Complies with EMI/RFI Regulations
• CE Compliant
International Safety Standard Approvals
Specifications
Output Specifications
Combined Line and Load
Voltage Regulation
Ripple
Transient Response
Protection
Excluding Cord
±1%
1% Vp-p max.
0.5ms for 50%
Load Change Typical
Foldback Overcurrent
Protection,
Short Circuit Protection
General Specifications
Topology
Dielectric Withstand
Spacing
Leakage Current
Efficiency
EMC Information
Emissions
Harmonic
VFF
ESD
RF EFI
EFT
Surge
CDI
CD
Voltage Dips
CE
Hold-up Time
Storage Temp
Primary-Secondary
Secondary-Ground
FCC Part 15.
EN55022.
EN61000-3-2
EN61000-3-3
EN61000-4-2.
EN61000-4-3.
EN61000-4-4.
EN61000-4-5.
EN61000-4-6.
EN61000-4-8.
EN61000-4-11
Switching-Fixed
Frequency Flyback
3000VAC, 4250VDC
500VDC
5mm Primary-Secondary
Less than 250 uA
65% Typical @ Max Load
and 120VAC/60 Hz
Class B
Class B
Level 2
Level 2
Level 2
Level 3
Level 2
Level 1
Input Specifications
AC Input Voltage Range
Line Frequency
AC Input Current
Protection
90VAC Input
100-240VAC -10%, +10%
47-63Hz
0.6A max.
Internal Primary
Current Fuse,
Inrush Limiting
Environmental Specifications
Thermal Performance
Relative Humidity
Altitude
Operating Temperature 0° C to 40° C
No Derating,
Convectional Cooling
Non Vented Case
Non-Condensing
5% to 95%
0-10,000 feet
LVD, EMC, RoHS, WEEE, CE Compliant
@120VAC
@240VAC
10ms min.
30ms min.
-30° C to +85° C
SL Power Electronics Corp
•
6050 King Drive
•
Ventura, CA 93003
•
Phone:805.486.4565
•
Fax:805.487.8911
•
Email:info@slpower.com
•
www.slpower.com
PW182RA
PoE Gigabit
Output
Voltage
48 V
Universal 19 Watt (IEEE802.3af Non-Compliant)
For the most current data and application support visit www.slpower.com
Output Currents
Min
0.00 A
Ault Part Number
PW182RA4800_01
Max
0.40 A
Max
Watts
19 W
Ripple
Vp-p max.
480 mV
Ault Part Number Key
R
Manufacturing
Location
(volume dependent)
A
Design
Revision
Changes
48
Voltage
DC
Model Type
00
Connector
_
Input
Configuration/
Model Type
01
Standard
(no modifications
or special packaging)
PW182
Product
Family
Name
Input Configuration
Note: Call for optional
configurations, extra
charges may apply.
N. America/
Europe
Japan
(B)
(M)
Pin Connections
United
Kingdom
(G)
IEC320
Australian
w/ground
(E)
C14
(F)
IEC320
Shaver
w/o
C8 ground
C18
(N)
(Q)
United
Kingdom
(G)
Australian
(E)
Shaver
C8
(N)
Specify the Input Configuration Code in your order.
General Specifications (continued from p. 1)
Approvals and
Standards
MTBF
Weight
Case and Dimension
Case Material
Safety
cULus : UL/CSA60950
TUV : EN60950
CE: LVD, EMCD
100,000 Calculated Hours
7 Ounces, 200 Grams
5.24L x 2.13W x 1.42H (in)
133.0L x 54.0W x 36.0H (mm)
Impact Resistant
Polycarbonate Enclosure
Dual RJ45 jacks built into
the enclosure
Data
Note:
Data
87654321
87654321
J2
(Power and Data Out)
(Rear of Unit)
J1
(Data In)
PoE Gigabit Pin-out Connections:
POWER (+)
Data
Pins 4/5 (Data + PWR)
Data
Pins 1/2 (Data Only)
Pins 3/6 (Data Only)
POWER (-)
Cord and Connectors
Pins 7/8 (Data + PWR)
= Transformer
Personalized PoE
Options (additional costs may apply):
• Energy Star (LED must be removed to meet)
• Custom label artwork
• Custom agency approvals available
• Surge protection (Input & Output)
• Mounting bracket
• Custom PoE modifications
SL Power Electronics Corp
•
6050 King Drive
•
Ventura, CA 93003
•
Phone:805.486.4565
•
Fax:805.487.8911
•
Email:info@slpower.com
•
www.slpower.com
Data Sheet © 2007 SL Power Electronics Corp. The information and specifications contained in this data sheet are believed to be correct at time of publication.
However, SL Power accepts no responsibility for consequences arising from reproduction errors or inaccuracies. Specifications are subject to change without notice.
Rev.12/21/07
