Features
Regulated
Converters
●
AC-DC Power Supply
●
5 Watt PCB Mount Package
●
Universal Input Voltage Range
●
3000VAC Isolation
●
Low Output Ripple and Noise
●
Short Circuit Protected
●
UL Approved, CE Marked
Compact UL certified switching AC/DC power module for PCB,
screw-terminal connection or DIN-rail mounting.
POWERLINE
AC/DC-Converter
with 3 year Warranty
Description
Selection Guide
Part
Number
RAC05-3.3SA
RAC05-05SA
RAC05-12SA
RAC05-15SA
RAC05-24SA
Input
Range
(VAC)
90-264
90-264
90-264
90-264
90-264
90-264
90-264
90-264
Output
Voltage
(VDC)
3.3
5
Output
Current
(mA)
1500
1000
416
333
200
Efficiency
(%)
62
65
Max
Capacitive
Load
40000µF
19000µF
4000µF
3500µF
900µF
5 Watt
Single/Dual
Output
RAC05-05DA
RAC05-12DA
RAC05-15DA
NOT RECOMMENDED
FOR
NEW DESIGNS
12
15
24
70
70
71
±5
±500
70
±12
±15
±200
±160
67
67
±9500µF
±1400µF
±950µF
*add suffix “-E” for extended temperature range, e.g. RAC05-05SA-E
*add suffix "-ST” for screw terminal module e.g. RAC05-05SA-ST, RAC05-05DA-E-ST
Specifications
(typical at 25°C and after warm up time unless otherwise specified )
Input Voltage Range
Rated Power
Input Frequency Range (for AC Input)
Input Current (full load)
No Load Power Consumption
Inrush Current (<2ms)
Leakage Current
Output Voltage Accuracy (full load)
Line Voltage Regulation (low line, high line at full load)
Load Voltage Regulation ( 5% to 100% full load )
Output Ripple and Noise (20MHz limited)
Operating Frequency
Efficiency at full Load
RMS Isolation Voltage (input to output)
Temperature Coefficient
Isolation Resistance
Short Circuit Protection
Operating Temperature Range
(free air convection, with derating)
Storage Temperature Range
Humidity
Case Material
Package Weight
Packing Quantity
EMC
MTBF (+25°C)
PA-26
using MIL-HDBK-217F
REV: 1/2014
Standard
Suffix -E
Ripple
Noise
115VAC/230VAC
115VAC/230VAC
115VAC
230VAC
90-264VAC or 120-370VDC
5 Watts max
47-440Hz
120mA /70mA max.
1.18W max.
10A max. (-E = 23A max.)
20A max. (-E = 46A max.)
0.75mA max
±2%
±0.3% typ
±0.5% typ
<0.2% Vout + 40mVp-p max
0.5% Vout + 50mVp-p max
100kHz typ
see table
Output Power (%)
2011/65/EU
6/6
RoHS
E196683
UL-60950-1 Certified
RAC05-A
Derating-Graph
(Ambient Temperature)
125
100
75
50
25
0
-40 -25 -10 0
60 70 80 90
E-Version
3kVAC / 1minute
±0.02%/°C typ
100 MΩ max
Hiccup, Automatic Restart
-25°C to +70°C
-40°C to +70°C
-40°C to +85°C
95% RH max
Epoxy with Fibreglass (UL94V-0)
80g
5 pcs (-ST Version: 1 pc)
EN 55022 ClassB / EN 50082-1
300 x 10 hours
3
Natural Convection
50
Ambient Temperature Range (°C)
Refer to Application Notes
www.recom-power.com
POWERLINE
AC/DC-Converter
Screw Terminal Module Option (suffix -ST)
RAC05-S_DA
Series
Pin Connections-
Pin #
1
2
3
4
5
6
7
8
Single Out
FG
VAC in (N)
VAC in (L)
NC
-VDC out
NC
+VDC out
NC
Dual Out
FG
VAC in (N)
VAC in (L)
NC
-VDC out
Com
+VDC out
NC
NC = No Connection
Standard Package Style and Pinning
55.00
45.00
20.5
RAC05-A
8.0
47.00
1.0
Pin Connections-
Pin #
1
3
L
+
6
Single Out
FG
VAC in (N)
VAC in (L)
-VDC out
No Pin
+VDC out
Dual Out
FG
VAC in (N)
VAC in (L)
-VDC out
Com
+VDC out
2
10.0
17.5
2
N
Bottom View
3
4
Com
5
17.5
1 FG
10.0
-
4
5
6
XX.X ± 0.5 mm
XX.XX ± 0.25 mm
Standard Application Circuit
L
Suggested fuse rating
1A Slow Blow
E
N
Fuse
VACin (L)
FG
VACin (N)
Vout+
(Com)
Vout-
Load
Load
Load
Dual
Single
The product information and specifications are subject to change without prior notice. RECOM products are not authorized for use in safety-critical applications (such as life support) without RECOM’s explicit
written consent. A safety-critical application is defined as an application where a failure of a RECOM product may reasonably be expected to endanger or cause loss of life, inflict bodily harm or damage property. The buyer
shall indemnify and hold harmless RECOM, its affiliated companies and its representatives against any damage claims in connection with the unauthorized use of RECOM products in such safety-critical applications.
www.recom-power.com
REV: 1/2014
PA-27
