PYB15-Q24-D12

Description
Switching Controllers PWM Controller
Categorysemiconductor    Power management
File Size588KB,7 Pages
ManufacturerCUI
Websitehttp://www.cui.com
Download Datasheet Parametric Compare View All

PYB15-Q24-D12 Online Shopping

Suppliers Part Number Price MOQ In stock
PYB15-Q24-D12 - - View Buy Now

PYB15-Q24-D12 Overview

Switching Controllers PWM Controller

PYB15-Q24-D12 Parametric

Parameter NameAttribute value
Product CategoryIsolated DC/DC Converters
ManufacturerCUI
RoHSDetails
Number of Outputs2 Output
Output Power15 W
Input Voltage9 V to 36 V
Output Voltage-Channel 112 V
Output Current-Channel 1625 mA
Output Voltage-Channel 2- 12 V
Output Current-Channel 2625 mA
Isolation Voltage1.5 kVDC
Mounting StyleThrough Hole
Length50.8 mm
Width25.4 mm
Height16.3 mm
Commercial/MedicalCommercial
Operating Temperature Range- 40 C to + 85 C
PackagingBulk
ProductIsolated
Factory Pack Quantity19
Unit Weight1 oz
For more information, please visit the
product page.
date
page
06/15/2015
1 of 7
SERIES:
PYB15
DESCRIPTION:
DC-DC CONVERTER
FEATURES
• up to 15 W isolated output
• industry standard pinout
• 4:1 input range (9~36 Vdc, 18~75 Vdc)
• smaller package
• single/dual regulated outputs
• 1,500 Vdc isolation
• continuous short circuit, over current protection, over voltage protection
• temperature range (-40~85°C)
• UL 60950-1 approval
• six-sided metal shielding
• efficiency up to 90%
MODEL
typ
(Vdc)
input
voltage
range
(Vdc)
output
voltage
(Vdc)
min
(mA)
output
current
max
(mA)
output
power
max
(W)
ripple
and noise
2
max
(mVp-p)
efficiency
typ
(%)
PYB15-Q24-S3
PYB15-Q24-S5
PYB15-Q24-S12
PYB15-Q24-S15
PYB15-Q24-S24
PYB15-Q24-D5
PYB15-Q24-D12
PYB15-Q24-D15
PYB15-Q48-S3
1
PYB15-Q48-S5
1
PYB15-Q48-S12
1
PYB15-Q48-S15
1
PYB15-Q48-D5
PYB15-Q48-D12
PYB15-Q48-D15
Notes:
24
24
24
24
24
24
24
24
48
48
48
48
48
48
48
9~36
9~36
9~36
9~36
9~36
9~36
9~36
9~36
18~75
18~75
18~75
18~75
18~75
18~75
18~75
3.3
5
12
15
24
±5
±12
±15
3.3
5
12
15
±5
±12
±15
200
150
63
50
31
±75
±32
±25
200
150
63
50
±75
±32
±25
4000
3000
1250
1000
625
±1500
±625
±500
4000
3000
1250
1000
±1500
±625
±500
13.2
15
15
15
15
15
15
15
13.2
15
15
15
15
15
15
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
87
90
89
89
90
86
88
88
87
89
88
90
86
88
89
1. UL approved
2. Ripple and noise are measured at 20 MHz BW by “parallel cable” method with 1 µF ceramic and 10 µF electrolytic capacitors on the output.
PART NUMBER KEY
PYB15 - QXX -
XXX
-
X
Heatsink
"blank" = no heatsink
H = with heatsink
Base Number
Input Voltage
Output
S = single
D = dual
Output Voltage
