Global Use-Terminal Connection (185 Series)
Power
25 & 43 VA Mount
(Figure A)
80, 130 & 175 VA Mount
(Figure B)
GLOBAL USE - CHASSIS MOUNT
POWER TRANSFORMERS
•
•
•
•
•
•
•
•
•
•
•
•
Dual primary 115/230 VAC
50/60 Hz. operation
Dual secondaries for series or parallel connections
4,000 V RMS Hipot test
Class F insulation (155 degrees, C)
Chassis mount
5 different VA sizes to choose from
Dual bobbin construction
Dual use terminals (solder lug or quick connect)
C UL US recognized
TUV Type Approved
CE certified to IEC 950 (Approved to EN 60-742 Safety
Isolating Transformers)
Transformer Schematic
Primary
6
115V
5
2
115V
1
Secondary
7
SEC #1
8
11
SEC #2
12
For wiring diagrams - visit our website:
www.hammondmfg.com
Guelph, Ontario (519) 822-2960
St. Laurent, Quebec (514) 343-9010
©
Cheektowaga, NY (716) 630-7030
CANADA
USA
www.hammondmfg.com
Basingstoke, UK 01256 812812
Queenstown, Australia 61-8-8240-2244
EUROPE
32
AUSTRALIA
Global Use - Terminal Connection (185 Series)
Dual Primary 115/230 VAC 50/60 Hz.
Secondary VAC (R.M.S.)
Series
10V C.T. @ 2.5A
10V C.T. @ 4.3A
10V C.T. @ 8.0A
10V C.T. @ 13.0A
10V C.T. @ 17.5A
12.6V C.T. @ 2.0A
12.6V C.T. @ 3.4A
12.6V C.T. @ 6.3A
12.6V C.T. @ 10.3A
12.6V C.T. @ 14.0A
16V C.T. @ 1.6A
16V C.T. @ 2.7A
16V C.T. @ 5.0A
16V C.T. @ 8.1A
16V C.T. @ 11.0A
20V C.T. @ 1.25A
20V C.T. @ 2.2A
20V C.T. @ 4.0A
20V C.T. @ 6.5A
20V C.T. @ 8.8A
24V C.T. @ 1.0A
24V C.T. @ 1.8A
24V C.T. @ 3.3A
24V C.T. @ 5.4A
24V C.T. @ 7.3A
28V C.T. @ 0.9A
28V C.T. @ 1.5A
28V C.T. @ 2.8A
28V C.T. @ 4.6A
28V C.T. @ 6.25A
36V C.T. @ 0.7A
36V C.T. @ 1.2A
36V C.T. @ 2.2A
36V C.T. @ 3.6A
36V C.T. @ 4.8A
230V C.T. @ 0.11A
230V C.T. @ 0.19A
230V C.T. @ 0.35A
230V C.T. @ 0.57A
230V C.T. @ 0.76A
Parallel
5V @ 5.0A
5V @ 8.6A
5V @ 16.0A
5V @ 26.0A
5V @ 35.0A
6.3V @ 4.0A
6.3V @ 6.8A
6.3V @ 12.6A
6.3V @ 20.6A
6.3V @ 28.0A
8V @ 3.2A
8V @ 5.4A
8V @ 10.0A
8V @ 16.2A
8V @ 22.0A
10V @ 2.5A
10V @ 4.4A
10V @ 8.0A
10V @ 13.0A
10V @ 17.6A
12V @ 2.0A
12V @ 3.6A
12V @ 6.6A
12V @ 10.8A
12V @ 14.6A
14V @ 1.86A
14V @ 3.0A
14V @ 5.6A
14V @ 9.2A
14V @ 12.5A
18V @ 1.4A
18V @ 2.4A
18V @ 4.4A
18V @ 7.2A
18V @ 9.6A
115V @ 0.22A
115V @ 0.38A
115V @ 0.7A
115V @ 1.14A
115V @ 1.52A
Dimensions
(Inches)
W
2.81
3.12
2.50
2.81
3.12
2.81
3.12
2.50
2.81
3.12
2.81
3.12
2.50
2.81
3.12
2.81
3.12
2.50
2.81
3.12
2.81
3.12
2.50
2.81
3.12
2.81
3.12
2.50
2.81
3.12
2.81
3.12
2.50
2.81
3.12
2.81
3.12
2.50
2.81
3.12
D
2.22
2.22
2.61
3.07
3.20
2.22
2.22
2.61
3.07
3.20
2.22
2.22
2.61
3.07
3.20
2.22
2.22
2.61
3.07
3.20
2.22
2.22
2.61
3.07
3.20
2.22
2.22
2.61
3.07
3.20
2.22
2.22
2.61
3.07
3.20
2.22
2.22
2.61
3.07
3.20
H
2.31
2.68
3.00
3.37
3.75
2.31
2.68
3.00
3.37
3.75
2.31
2.68
3.00
3.37
3.75
2.31
2.68
3.00
3.37
3.75
2.31
2.68
3.00
3.37
3.75
2.31
2.68
3.00
3.37
3.75
2.31
2.68
3.00
3.37
3.75
2.31
2.68
3.00
3.37
3.75
1.25
1.75
2.50
4.00
5.00
1.25
1.75
2.50
4.00
5.00
1.25
1.75
2.50
4.00
5.00
1.25
1.75
2.50
4.00
5.00
1.25
1.75
2.50
4.00
5.00
1.25
1.75
2.50
4.00
5.00
1.25
1.75
2.50
4.00
5.00
1.25
1.75
2.50
4.00
5.00
A
A
B
B
B
A
A
B
B
B
A
A
B
B
B
A
A
B
B
B
A
A
B
B
B
A
A
B
B
B
A
A
B
B
B
A
A
B
B
B
Weight
(lbs)
Hole to
Hole
Mtg. Dim.
(Inches)
W
2.37
2.81
2.00
2.25
2.50
2.37
2.81
2.00
2.25
2.50
2.37
2.81
2.00
2.25
2.50
2.37
2.81
2.00
2.25
2.50
2.37
2.81
2.00
2.25
2.50
2.37
2.81
2.00
2.25
2.50
2.37
2.81
2.00
2.25
2.50
2.37
2.81
2.00
2.25
2.50
D
-
-
2.18
2.50
2.50
-
-
2.18
2.50
2.50
-
-
2.18
2.50
2.50
-
-
2.18
2.50
2.50
-
-
2.18
2.50
2.50
-
-
2.18
2.50
2.50
-
-
2.18
2.50
2.50
-
-
2.18
2.50
2.50
Power
Part No.
VA
Fig.
185C10
185D10
185E10
185F10
185G10
185C12
185D12
185E12
185F12
185G12
185C16
185D16
185E16
185F16
185G16
185C20
185D20
185E20
185F20
185G20
185C24
185D24
185E24
185F24
185G24
185C28
185D28
185E28
185F28
185G28
185C36
185D36
185E36
185F36
185G36
185C230
185D230
185E230
185F230
185G230
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
25
43
80
130
175
VA Size
25, 43
80, 130 & 175
Fig.
A
B
Terminal Lug Data
Width
Thickness
0.187”
0.020”
0.25”
0.032”
