www.murata-ps.com
DMS Accessories
Connectors and Sockets
DESCRIPTION
Murata Power Solutions' 4320-01069-0 six position connector housings and 4400-01032-0 crimp
terminals provide a secure method for making input/output connections to all panel mounted 12-pin DMS
series meters. These connectors are ideal for use in low-volume prototype applications. Two connector
housings and 12 terminals are required for each meter.
Connector Housing
A
0.62
(15.7)
B
0.19
(4.8)
C
0.50
(12.7)
6-Position Connector Housing
A
4320-01069-0
Dimensions: in. (mm) All dimensions are nominal
Crimp Terminal
4400-01032-0
A
0.042
(1.07)
E
0.38
(9.7)
B
0.08
(2.0)
F
0.05
(1.3)
C
0.08
(2.0)
G
0.08
(2.0)
D
0.06
(1.5)
H
0.075
(1.91)
B
C
Dimensions: in. (mm) All dimensions are nominal
Electrical Specifications
Crimp Terminals
B
A
C
Insulator Material:
Flammability Rating:
Wire Size:
Stripping Length:
Current Rating:
Insulation Diameter:
Nylon
UL94V-0
22-26 AWG
0.100" to 0.125" (2.54 to 3.17mm)
2.5A continuous
0.062" (1.57mm) max.
Crimp Terminal and Housing Installation
D
E
F
G
H
Wire
Crimp
Terminal
Connector Housing
0.100-0.125" (2.54-3.17mm)
0.062" (1.57mm) max.
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com/support
MPM_DMS_Connectors.C01
Page 1 of 2
DMS Accessories
Connectors and Sockets
DESCRIPTION
Murata Power Solutions' 6-position SIP and 12-position DIP sockets provide any easy and inexpen-
sive, low profile solution for mounting DMS series meters on printed circuit boards. These are the same
rugged, long-life sockets Murata Power Solutions uses in all its in-house panel meter burn-in boards.
Both sockets provide excellent mechanical retention force, and in many applications they can supply all
the necessary mechanical force to hold the meters in position (see DMS Application Note 16 for more
information). The 6-position SIP’s can be used with all 12-pin DMS meters, while the 12-position DIP’s are
intended for use with “-BCD” models of the DMS-40PC family.
12-Position DIP Socket
A
0.620
(15.7)
6-Position SIP Socket
A
0.620
(15.7)
B
0.335
(8.51)
B
0.335
(8.51)
C
0.031
(0.79)
C
0.031
(0.79)
D
0.016
(0.41)
D
0.016
(0.41)
E
0.195
(4.95)
E
0.098
(2.48)
6-Position SIP Sockets
A
E
4320-01072-0
B
4320-01074-0
Dimensions: in. (mm) All dimensions are nominal
Meter and Socket Installation
Meter
0.100
(2.54)
Socket
PC Board
C
D
12-Position DIP Sockets
A
0.33-0.40 typ.
E
Electrical Specifications
Insulator Material:
Black liquid crystal polymer
UL94V-0
–65 to +105°C
Matte Tin
0.037 (0.94) to 0.043 (1.09)
Phosphor Bronze
3A continuous
5 oz. (1.39N) avg./position with 0.025 (0.64) pin
B
Flammability Rating:
Operating Temperature:
Contact & Tail Plating:
PC-board Hole Diameter:
Contact Material:
0.100
(2.54)
C
D
Current Rating:
Withdrawal Force:
