6
5
4
3
2
1
n
1,16 (15x)
(5:1)
D
9,6
`
0,3
SEALING
COMPOUND
D
0,8
39,22
+ 0,3
- 0,46
33,32
+ 0,13
- 0,12
12,4
+ 0,53
- 0,23
24,74
+ 0,05
- 0,2
8
+ 0,02
- 0,23
C
6,13
+ 0,17
- 0,08
4,5
C
10°
2,55
242
o
26990X
CONEC ABC
4-40 UNC
SEE NOTE 11
NOTES:
1. RoHS COMPLIANT
2. METALSHELLS: STEEL; min. 315µin TIN over 40-80µin NICKEL
3. INSULATOR: HIGH TEMPERATURE PLASTIC UL 94 V-0, BLACK
4. CONTACTS: COPPER ALLOY; PLATING (SEE PART NO):
o
PLEASE ADD C for 30µin HARD GOLD over min. 50µin NICKEL
o
PLEASE ADD B for 20µin HARD GOLD over min. 50µin NICKEL
o
PLEASE ADD A for GOLD FLASH over NICKEL (PREFERRED TYPE)
B
B
SOLDER CUP ACCEPTS CABLE AWG 20
5. THREADED INSERTS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
6. COLLARS: COPPER ALLOY; min. 200µin TIN over 80µin NICKEL
7. SEALING COMPOUND: PUR; BLUE
8. CAPACITANCE: 830pF
`
20%
9. DIELECTRIC WITHSTANDING VOLTAGE: 424 VDC
10. MAXIMUM TORQUE VALUE FOR THREAD: 6 in.LB
11. CONNECTOR IS PART MARKED: 242
o
26990X CONEC ABC (see note 4)
THIS DRAWING MAY NOT BE COPIED OR
REPRODUCED IN ANY WAY, AND MAY NOT
BE PASSED ON TO A THIRD PARTY WITHOUT
WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC GmbH
DO NOT ALTER CAD DRAWING BY HAND
tolerance
dim. in mm
date
name
scale:
material:
title:
2:1 (5:1)
see notes
A
A
drawn
11.03.13 Lehmenkühler
appd.
12.03.13
norm
d-old
R
D-SUB FILTER FEMALE
15pos. SOLDER CUP
with threaded insert
dwg no:
DIN-
A3
sh:
1
Fischer
Directive 2002/95/EC RoHS compliant
6
5
a
Original
24K1A1434
part no:
rev. description
4
date
name
3
242
o
26990X
2
(see note 4)
