31762-36 Overview

Capacitor Hardware SIDE MOUNT BRKT

31762-36 Parametric

Parameter Name	Attribute value
Product Category	Capacitor Hardware
Manufacturer	Cornell Dubilier
RoHS	Details
Packaging	Bulk
Factory Pack Quantity	1

Preview

Download Datasheet

View All

Capacitor Hardware

Type VR Vertical Mounting Clamp

Catalog Part Number

Diameter

of Part to be

Mounted

1" to 1-1/16

1-3/8" to 1-7/16

1-1/2" to 1-9/16

1-3/4" to 1-13/16

2" to 2-1/16

2-1/2" to 2-9/16

3" to 3-1/8

Screw

Nut

Without

Screw & Nut

VR1B

VR3B

VR4B

VR6B

VR8B

VR10B

VR12B

VRSCREW

VRNUT

Unassembled

Screw & Nut

Included

VR1

VR3

VR4

VR6

VR8

VR10

VR12

—

Assembled

with

Screw & Nut

VR1A

VR3A

VR4A

VR6A

VR8A

VR10A

VR12A

—

1-3/8"

1-1/2"

1-3/4"

2-1/2"

1-7/16"

1-25/32"

1-15/16"

2-1/4"

2-1/2"

3-7/16"

1-7/8*"

2-7/32"

2-11/32"

2-9/16"

2-13/16"

3-5/16"

3-13/16"

Dimensions

9/16" long 6-32 thread NC-2A

Standard hex nut to fit screws

CDE VR mounting clamps may be

used to mount any cylindrical ca-

pacitor with a 1” to 3” diameter

that is to be mounted in a verti-

cal position. Material is 1010 CRS,

commercial grade #4 temper ASI

scale. Parts are finished with .0001

(nominal) zinc chromate plating.

Use for mounting CG types, PSU, SF

and MPF types. Material thickness

is .035”

VR1, 3 & 4

.219”

.375”

C ±0.01”

0.176” x 0.281”

±0.016 (3 places).

VR6, 8,10 & 12

B Mtng ±0.03”

B Mtg

2 Holes

.1561” Dia.

.156”

120 º ±3 º

(3 Places)

.562” .750”

B Mtng ±0.03”

Ø 0.201” ±0.005”

0.18

75 º

A ±0.016”

0.34

4” ±

8” ± 016”

0.01

6”

Type TH Horizontal Mounting Clip

Dimensions in Inches

Nominal Dia.

Catalog

Part Number

of Part to be

Mounted

0.375”±0.016”

1.125” ±0.016”

0.035”

0.075” ±0.016”

0.500” ±0.016”

0.015

0.030

(*)

(*) 0.340" except TH25 is 0.590".

TH17

TH25

0.625

1.375

Added tolerance to "C" dim.

0.312 0.720

0.312 1.500

Material Thickness

TH17 is 0.016”, TH25

is 0.025”.

Material: 1050 high

carbon steel with

phosphate and oil

finish. TH25 is 1060.

(*) 0.340” execpt TH25 is 0.590”

Retaining tabs

Retaining

must

extendtabs must

extend

lower

than base

base

than

of clip

C ±0.010"

These clips, though designed for

capacitors, have varied applica-

tions to retain many cylindrical

components. They are used ex-

tensively in the electrical and elec-

tronic industries to hold spindles,

condensers, capacitors, tubes,

rods and conduit. Clips have phos-

phate and oil finish.

Material thickness TH13 thru TH17

is .016”. TH21 thru TH25 is .020”

0.135" Dia. Hole

0.135” Dia. Hole

0.594"

ACR15KT Motor Start Resistor Kit

ACR220KT Motor Run Resistor Kit

15K Ohm 2 watt bleeder resistors for AC motor start applica-

tions. Saves relay switch contacts and capacitor, particularly in

capacitor start applications. 1/4” quick connect terminals elimi-

nate need for soldering.

ACR15K:

Pack of 10, 15K Ohm 2 watt bleeder resistor without quick con-

nect terminals.

220K Ohm 1 watt bleeder resistors for AC motor run applica-

tions. Saves relay switch contacts and capacitor, particularly in

capacitor run applications. 1/4” quick connect terminals elimi-

nate need for soldering.

ACR220K:

Pack of 10, 220K Ohm 1 watt bleeder resistor without quick con-

nect terminals.

CDE Cornell Dubilier

•

1605 E. Rodney French Blvd.

•

New Bedford, MA 02744

•

Phone: (508)996-8561

•

Fax: (508)996-3830

•

www.cde.com

Capacitor Hardware

Notice and Disclaimer:

All product drawings, descriptions, specifications, statements, information and data

(collectively, the “Information”) in this datasheet or other publication are subject to change. The customer

is responsible for checking, confirming and verifying the extent to which the Information contained in this

datasheet or other publication is applicable to an order at the time the order is placed. All Information given

herein is believed to be accurate and reliable, but it is presented without any guarantee, warranty, representation

or responsibility of any kind, expressed or implied. Statements of suitability for certain applications are based

on the knowledge that the Cornell Dubilier company providing such statements (“Cornell Dubilier”) has

of operating conditions that such Cornell Dubilier company regards as typical for such applications, but

are not intended to constitute any guarantee, warranty or representation regarding any such matter – and

Cornell Dubilier specifically and expressly disclaims any guarantee, warranty or representation concerning

the suitability for a specific customer application, use, storage, transportation, or operating environment.

The Information is intended for use only by customers who have the requisite experience and capability to

determine the correct products for their application. Any technical advice inferred from this Information or

otherwise provided by Cornell Dubilier with reference to the use of any Cornell Dubilier products is given

gratis (unless otherwise specified by Cornell Dubilier), and Cornell Dubilier assumes no obligation or liability

for the advice given or results obtained. Although Cornell Dubilier strives to apply the most stringent quality

and safety standards regarding the design and manufacturing of its products, in light of the current state

of the art, isolated component failures may still occur. Accordingly, customer applications which require a

high degree of reliability or safety should employ suitable designs or other safeguards (such as installation

of protective circuitry or redundancies or other appropriate protective measures) in order to ensure that the

failure of an electrical component does not result in a risk of personal injury or property damage. Although

all product-related warnings, cautions and notes must be observed, the customer should not assume that all

safety measures are indicated in such warnings, cautions and notes, or that other safety measures may not be

required.

CDE Cornell Dubilier

•

1605 E. Rodney French Blvd.

•

New Bedford, MA 02744

•

Phone: (508)996-8561

•

Fax: (508)996-3830

•

www.cde.com
