510
Features
□
Heavy duty 54A 277VAC, 50A 400VAC power type.
□
DPDM contact configuration with large contact gap
2.1mm / 3.0mm version.
□
Conforms to European photovoltaic standard IEC 62109-1.
□
Coil holding voltage can be reduced to 50~55% V of the
nominal coil voltage for saving energy.
□
High performance PCB power relay for photovoltaic power
generation systems (solar inverter).
□
Complies with RoHS-Directive 2011/65/EU.
Type List
Terminal style
Contact form
Contact gap
2.1mm
PCB terminal
2A
(DPDM)
3.0mm
Ordering Information
Designation (provided with)
Dust cover
510H-P-2A-F-D
------
510H-P-2A1-F-D
------
Ftlux tight
510H-P-2A-F-C
510C-P-2A-F-C
510H-P-2A1-F-C
510C-P-2A1-F-C
510
1
1. 510
2. H
C
3. P
4. 2A
H
2
-
P
3
-
2A
4
-
5
6
-
C
7
5. Blank
1
6. Blank
F
7. C
D
8.
8
-- Contact gap ≥2.1mm
-- Contact gap ≥3.0mm
-- Standard type
-- Class F
-- Flux tight
-- Dust cover
-- Coil voltage (please refer to the
coil rating data for the availability)
-- Basic series designation
-- High power type
-- Characteristic flexible type
-- PCB terminal
-- Form A, double-pole, double-make
(DPDM)
Contact Rating
Type
Rated load (Resistive)
Max. switching current
Max. switching voltage
Coil Rating (DC)
Rated
voltage
(V)
12
24
Rated current Coil resistance
±10 % at 23°C ±10 % at 23°C
(mA)
(Ω)
449
226
26.7
106
Pick up
voltage
(Max.)
at 23°C
(1)
75 % of
rated
voltage
Drop out
voltage
(Min.)
at 23°C
5 % of
rated
voltage
Continuous
voltage
at 85°C
(2)
50~55 % of
rated
voltage
Power
consumption
at rated / holding
voltage
approx.
5.4W / 1.35W
(2)
510H
54A 240VAC, On 1s /Off 9s, at
85°C, 10K ops.
54A
277VAC
510C
50A 240VAC, On 1s /Off 9s, at 85°C, 6K ops.
Making 20A, Carrying 50A, Breaking 20A /
400VAC, On 1s /Off 9s, at 85°C, 30K ops.
50A
400VAC
Notes : (1) To energize relay properly apply 100%~120% nominal coil voltage for 200ms.
(2) Coil holding voltage is 50~55% of nominal voltage after applying nominal voltage for 200ms.
29
510
Specification
Contact material
Contact resistance
(1)
Operate time
(1)
Release time
(1)
Vibration resistance
Shock resistance
Life expectancy
Operating ambient temperature
Weight
Ag alloy
100mΩ Max. (at 1A/6VDC by 4-wire resistance measurement)
6 mΩ Max. (By voltage drop 10A)
30ms Max.
30ms Max.
Operating extremes
Damage limits
Operating extremes
Damage limits
Mechanical
10~50Hz , amplitude 1.5 mm
10~50Hz , amplitude 1.5 mm
10G
100G
1,000,000 ops.
(frequency 9,000 ops./hr)
-40~+85°C (no freezing)
Approx.90 g
Notes : (1) Initial value. Operate and release time excluding contact bounce.
(2) Unless otherwise specified, all tests are under room temperature and humidity.
(3) Consider the heat of PCB is necessary, please check the actual condition of PCB.
(4) Applying no diode to this relay. The life expectancy will be lower when a diode is used. To use
a varistor (ZNR) could absorb the coil surge of relay that is recommended.
(5) Do not use the relay exceeding the coil rating, contact rating and life expectancy, or this may cause
the risk of overheating.
(6) To assure optimum performance, avoid the relay from dropping, hitting, or other unnecessary shocks.
(7) Do not switch the contacts without any load as the contact resistance may become increased rapidly.
(8) Please contact Song Chuan for the detailed information.
Insulation Data
Insulation resistance
(1)
Dielectric strength
(1)
Insulation of IEC 61810-1
Between coil to contact
: Double /Reinforce,
≥3.0mm
/
≥5.0
mm (for 250VAC)
≥3.0mm
/
≥8.0
mm (for 400VAC of 510C type)
: Basic,
≥1.5
mm/
≥2.5
mm
≥3.0
mm/
≥4.0
mm (for 400VAC & 2A1 of 510C
type only)
: Double /Reinforce,
≥3.0mm
/
≥5.0
mm (for 250VAC)
≥3.0mm
/
≥8.0
mm (for 400VAC of 510C type)
1000MΩ Min. (DC 500V)
Between open contact
Between contact circuits
: AC 2000V, 50/60Hz 1 min.
: AC 2000V, 50/60Hz 1 min.
Between contact and coil : AC 4000V, 50/60Hz 1 min.
Clearance / creepage
distances
Between open contact
Between contact circuits
Rated insulation voltage
Rated impulse withstand
voltage
Pollution degree
Rated voltage
Overvoltage category
250V (for 510H type), 250V/400V (for 510C type)
2500V
2
230 / 400V
II
2.1 mm Min. (IEC 62109-1 and VDE 0126)
3.0 mm Min. (IEC 62109-1 and VDE 0126)
Compliant with European photovoltaic standard
Contact gap
Notes : (1) Initial value.
30
510
Safety Approval
Certified
File No.
Safety Approval Rating
UL / CUL
E88991
TUV
R50199385
♦
510H type
UL / CUL
54A 277VAC
TUV
54A 250VAC
♦
510C type
UL / CUL
20A 277VAC, Resistive, Carrying current 50A
20A 400VAC, Resistive, Carrying current 50A
(1)
TUV
Making 20A , Carrying 50A , Breaking 20A/400VAC
(2)
Notes : (1) For Non-Industrial application use only.
(2) With 50%~55% modulation of nominal coil voltage.
Outline Dimensions
51.5
(2.028)
36.4
(1.433)
11
(0.331)
14.4
2
3
4
(1.368)
8.4
(0.433) (0.567)
1
(0.734)
18.65
6
40
(0.157)
(1.575)
5
4
0.8-4
(0.031)
1.2-2
(0.047)
0.8-2
(0.031)
6.3-4
(0.248)
(1.417)
(1.528)
38.8
36
34.75
TOLERANCE:
LESS THAN: 1(0.039)
±0.1(0.004)
5(0.197)
±0.3(0.012)
20(0.787)
±0.5(0.020)
MORE THAN: 20(0.787)
±1(0.039)
Wiring Diagram
(Bottom view)
1
2
3
4
6
5
36.4
PC Board Layout
(Bottom view)
1.2x6.7-4
(0.047x0.264)
(1.433)
8.4
(0.433) (0.567)
(0.331)
(0.734)
11
14.4
Ø1.75
(0.069)
40
(1.575)
- All specifications subject to change. Please contact Song Chuan for update. -
18.65
31
