NOTES:
1. KIT COMES FULLY ASSEMBLED
2. KIT INCLUDES BUSBAR, MOUNTING BRACKETS,
INSULATORS, AND MOUNTING HARDWARE.
L
3. DIMENSIONS IN PARENTHESIS ARE
MILLIMETERS.
C
US
.44 DIA THRU-HOLE
[11.2]
W
S1
LISTED
GROUNDING AND BONDING EQUIPMENT
INSULATION
MOUNTING HOLE
.25
[6.4]
2.75
[69.9]
OVERALL HEIGHT
PANDUIT
PART NUMBER
GB2D0008TPI-1
GB2D0021TPI-1
GB2D0033TPI-1
GB2D0044TPI-1
GB2D0056TPI-1
DIMENSIONS - IN [mm]
L
12.00
[304.8]
24.00
[609.6]
36.00
[914.4]
48.00
[1219.2]
60.00
[1524.0]
W
2.00
[50.8]
2.00
[50.8]
2.00
[50.8]
2.00
[50.8]
2.00
[50.8]
HOLE SIZE
7/16"
7/16"
7/16"
7/16"
7/16"
HOLE PATTERN INFORMATION
HOLE SPACING
1.00
1.00
1.00
1.00
1.00
# OF HOLE SETS
8 SETS
21 SETS
33 SETS
44 SETS
56 SETS
MOUNTING
BRACKET
HARDWARE
BUTTON HEAD
SCREW
BUTTON HEAD
SCREW
BUTTON HEAD
SCREW
HEX BOLT
HEX BOLT
MOUNTING KIT
QUANTITY
2
2
2
3
3
.44 DIA TYP.
[11.2]
ASSEMBLED AS SHOWN
05
04
12/10 JHNU JHNU
REVISED AGENCY LOGO
01/09
JESH JESH
UPDATED TITLE BLOCK "D" PATTERN GROUNDING BUS BARS
CUSTOMER DRAWING. WAS "A" PATTERN GROUNDING BUS BARS
CUSTOMER DRAWING
N41743BB-C41743
FLD
FLD
CORP.
UNLESS OTHERWISE SPECIFIED
DIMENSIONAL TOLERANCES ARE:
(.X)
(.XXX)
(.XX)
ANGLES
DRAWN BY
DATE
TINLEY PARK, ILLINOIS
"D" PATTERN GROUNDING BUSBARS
CUSTOMER DRAWING
UNLESS OTHERWISE SPECIFIED,
ALL DIMENSIONS ARE GIVEN IN
INCHES, THIRD ANGLE PROJECTION
03
02
01
00
REV
11/08 JHNU JHNU
REVISED DRAWING LAYOUT, REMOVED BRACKET VIEWS
11/08 JHNU
DWDA ADDED MOUNTING HARDWARE COLUMN TO TABLE
7/08
5/08
DATE
JHNU
DWDA
ADDED HOLE PATTERN COLUMN TO TABLE
JHNU
DWDA
BY
CHK
JHNU
1/08
MAT'L:
SCALE
NONE
DWG
DRAWING RELEASED
DESCRIPTION
ECN
-R
SUP
DRAWING NO / CAD FILE
CHK'D
C41743_05
B
SIZE
