TITLE:
NUT, AHD SERIES, 35mm
DWG NO:
AHD17-PN01
REV:
A4
SH:
1
OF:
1
REVISIONS
REV
A3
A4
ECO
DESCRIPTION
RELEASE NEW DWG FORMAT
ADDED AHD17-PN01-GRN & CHART
DATE
24JUL13
15DEC14
BY
DRP
JAH
APPR
A
9.5
39.7
M35x1
A
SECTION
A-A
NOTES: UNLESS OTHERWISE SPECIFIED
1. MATERIAL: THERMOPLASTIC
2. COLORS:
BLACK: P/N AHD17-PN01
GREEN: P/N AHD17-PN01-GRN
3. RoHS COMPLIANT
4. ALL DIMENSIONS ARE FOR REFERENCE USE ONLY.
QUANTITY
AHD17-PN01
DESCRIPTION
PART NUMBER
MATERIALS LIST
SIGNATURES
DRAWN:
CHECKED:
ENGINEER:
APPROVAL:
ITEM
UNLESS OTHERWISE SPECIFIED
1) All dimensions are in metric(mm).
2) Tolerances are as follows:
1 PL DEC
±0.30
Fractions
±1/64
2 PL DEC
±0.15
Angles
±1°
3 PL DEC
±0.08
3) Note reference =
DATE
D.PARKS
24JUL13
Amphenol
Sine Systems - www.amphenol-sine.com
44724 Morley Drive
Clinton Township, MI 48036
X
MATERIAL SPECIFICATIONS:
CUSTOMER:
THIS DRAWING IS SUPPLIED FOR
INFORMATION ONLY. DESIGN FEATURES,
SPECIFICATIONS AND PERFORMANCE DATA SIZE
SHOWN HEREON ARE THE PROPERTY OF
THE AMPHENOL CORPORATION. NO RIGHTS
OF REPRODUCTION ARE IMPLIED. ALL
DIMENSIONS ARE SUBJECT TO NORMAL
SCALE:
MANUFACTURING VARIATIONS.
NUT, AHD SERIES, 35mm
TYPE
DWG NO:
PROCESS SPECIFICATIONS:
REVISION
A C-
NONE
AHD17-PN01
SHEET
A4
1
OF
NEXT ASS'Y:
AHD17-9-1939PES
1
