XPLAWT-00-0000-0000V40E2 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> XPLAWT-00-0000-0000V40E2

XPLAWT-00-0000-0000V40E2: DescriptionSingle Color LED,; CategoryLED optoelectronic/LED photoelectric; File Size3MB，35 Pages; ManufacturerCree; Websitehttp://www.cree.com/; Environmental Compliance

Download Datasheet Parametric View All

XPLAWT-00-0000-0000V40E2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	XPLAWT-00-0000-0000V40E2	-	-	View	Buy Now

XPLAWT-00-0000-0000V40E2 Overview

Single Color LED,

XPLAWT-00-0000-0000V40E2 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	8161371554
Reach Compliance Code	unknown
Date Of Intro	2016-02-23
Other features	UL RECOGNIZED
color	WHITE
Configuration	SINGLE
Maximum forward current	3 A
Maximum forward voltage	3.25 V
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Optoelectronic device types	SINGLE COLOR LED
total height	2.68 mm
method of packing	TR, 7 INCH
Maximum reverse voltage	5 V
shape	ROUND
size	3.9 mm
surface mount	YES
T code	T-3/4
Terminal pitch	2.8 mm
perspective	125 deg

Preview

Download Datasheet

View All

CLD-DS97 Rev 4G

Product family data sheet

Cree

XLamp

XP-L LEDs

XP-L High Density LED

XP-L High Intensity LED

ProDuCt DEsCrIPtIon

XLamp

XP-L LeDs are available in two

versions: High Density and High Intensity.

FEAturEs

•

Available in white, 70-CRI white, 80-CRI

white, 85 CRI white and 90-CRI white

ANSI-compatible chromaticity bins

Binned at 85 °C

Maximum drive current: 3000 mA

Low thermal resistance: 2.2 °C/W

Wide viewing angle: 125° (XP-L High

Density), 115° (XP-L High Intensity)

•

Unlimited floor life at

≤ 30 ºC/85% RH

Reflow solderable - JEDEC J-STD-020C

electrically neutral thermal path

RoHS and ReACh compliant

recognized component (e349212)

•

tAbLE oF ContEnts

Characteristics ............................................2

Flux Characteristics - XP-L High Density ...3

Flux Characteristics - XP-L High Intensity .8

Relative Spectral Power Distribution ...... 12

Relative Flux vs. Junction Temperature

.. 12

electrical Characteristics ......................... 13

Relative Flux vs. Current .......................... 13

Relative Chromaticity vs. Current............ 14

Relative Chromaticity vs. Temperature ... 15

Typical Spatial Distribution...................... 16

Thermal Design ........................................ 16

Performance Groups – Luminous Flux... 17

Performance Groups – Chromaticity...... 18

Cree’s Standard Chromaticity Regions

Plotted on the 1931 CIe Curve ................ 21

Cree’s Standard Cool White Kits Plotted

on ANSI Standard Chromaticity

Regions ..................................................... 23

Cree’s Standard Warm and Neutral

White Kits Plotted on ANSI Standard

Chromaticity Regions .............................. 24

Cree’s Standard Chromaticity Kits

.......... 26

Bin and Order Code Formats ................... 27

Reflow Soldering Characteristics

............ 28

Notes ........................................................ 29

Mechanical Dimensions .......................... 31

Tape and Reel ........................................... 33

Packaging ................................................. 35

The XLamp XP-L High Density (HD) LeD

is the highest performing discrete in

Cree’s High Density (HD) class of LeDs,

delivering the next generation of lumen

output and efficacy in the compact

3.45 mm x 3.45 mm XP footprint.

Cree’s HD LeDs, optimized to deliver

maximum lumen output in a small form

factor, enable lighting manufacturers

to improve the performance of any

lighting design, create smaller and less

expensive systems, and develop new

lighting solutions that were previously

not possible.

The XLamp XP-L High Intensity (HI) LeD

is the first of Cree’s new class of High

Intensity (HI) LeDs optimized to deliver

maximum candela through secondary

optics. Built on Cree’s breakthrough SC5

Technology™ Platform, the XP-L HI LeD

delivers 120 percent more candela than

www.CRee.Com/XLAmp

the XP-L HD LeD through the same optic.

The XP-L HI LeD leverages the industry’s

highest single-die performance and a

new innovative primary optic design that

radically reduces the optical source size

to deliver both lumens and intensity.

and XLamp

are

registered trademarks and the Cree logo and SC5 Technology™ are trademarks of Cree, Inc. UL

and the UR logo are registered trademarks of UL LLC.

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300
