31BRCX-300-B1-20 datasheet, PDF

Datasheet> All Categories > Topical application> Mechanical and electrical/engineering/automation> 31BRCX-300-B1-20

31BRCX-300-B1-20: DescriptionEncoders Frameless Size 31 Heavy Duty Res; CategoryTopical application Mechanical and electrical/engineering/automation; File Size35KB，1 Pages; ManufacturerAPI Delevan; Websitehttp://www.delevan.com/

Download Datasheet Parametric View All

31BRCX-300-B1-20 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	31BRCX-300-B1-20	-	-	View	Buy Now

31BRCX-300-B1-20 Overview

Encoders Frameless Size 31 Heavy Duty Res

31BRCX-300-B1-20 Parametric

Parameter Name	Attribute value
Product Category	Encoders
Manufacturer	API Delevan
RoHS	Details
Product	Resolvers
Type	Absolute
Technology	Rotary
Packaging	Bulk
Factory Pack Quantity	1

Preview

Download Datasheet

View All

NOTES:

1 ROTOR AND STATOR TO BE AXIALLY ALIGNED WITH

-C-

WITHIN .015.

2. MAX. ERROR FROM E-Z OF ±20 MINUTES WHEN ROTOR IS MOUNTED ON SHAFT WHERE

RUNOUT IS .003 F.I.R. AND MOUNTING CONCENTRICITY OF STATOR IS .004 F.I.R.

3 ROTOR ID WILL FIT ON A 1.697/1.698 SLEEVE OD.

4 MOUNTING FACE CLEAN OF VARNISH.

.625

.620

TYPICAL MECHANICAL DATA

TEMPATURE RANGE

ºC -55 to +155

ROTOR MOMENT OF INERTIA OZ-IN-SEC²

.03

WEIGHT

OZ. AVG.

5.8

B IDENTIFY THE MANUFACTURING LOCATION

(ST. KITTS, WEST INDIES)

DELTRAN PT - HAROWE

31BRCX-300-B1/20

S/N:

D/C:

.187

NAMEPLATE

1007116-570

.125

TYPICAL ELECTRICAL DATA

INPUT VOLTAGE

VOLTS RMS

INPUT CURRENT

MAX. MA

NOM. WATTS

INPUT POWER

IMPEDANCE ZRO

OHMS

IMPEDANCE ZRS

OHMS

IMPEDANCE ZSO

OHMS

IMPEDANCE ZSS

OHMS

TRANSFORMATION RATIO

±10%

OUTPUT VOLTAGE

±10% VOLTS

DC ROTOR RESISTANCE

±15% OHMS

DC STATOR RESISTANCE

±15% OHMS

MAX ERROR

MINUTES

PHASE SHIFT (OPEN CIRCUIT)

NOM.

NULL VOLTAGE TOTAL RMS

HIPOT TO CASE

60HZ

VRMS

HIPOT BETWEEN PHASES 60HZ

VRMS

5000 HZ

4.0

.01

420+ J 810

230+ J 400

250+ J 455

140+ J 225

.500

2.0

102

±20

500

250

.500 MAX.

.210±.015

1.780 MIN

TYP

1.700

.001

2.950

3.050

3.048

.002

.154±.007

RED/WHT

RED

YELLOW

2 ROTOR LEADS#24 AWG (ET)

12" MIN. LENGTH

4 STATOR LEADS#24 AWG (ET)

12" MIN. LENGTH

YEL/WHT

ROTOR

PRIMARY

BLACK

BLUE

STATOR

SECONDARY

SCHEMATIC

PHASING EQUATION

FOR CCW ROTATION OF ROTOR FACING

TRANSFORMER MOUNTING FLANGE END.

E(S1-S3)= KE(R1-R2) COS Ø

E(S2-S4)= KE(R1-R2) SIN Ø

TOLERANCES

UNLESS SPECIFIED

DECIMAL

.XXX

±.005

DECIMAL

.XX

±.010

DECIMAL

±.030

FRACTION

±1/64

ANGLES

±0°30'

DRAWN

CHECKED

ENGR

DELTRAN PT - Harowe

PROPRIETARY RIGHTS OF DELTRAN PT - HAROWE ARE INCLUDED IN THE

INFORMATION DISCLOSED HEREIN. DO NOT DUPLICATE OR DISCLOSE TO

THIRD PARTIES WITHOUT WRITTEN PERMISSION OF DELTRAN PT.

THIS DRAWING HAS BEEN

CREATED BY CAD/CAM. DO NOT

MANUALLY REVISE OR UPDATE.

C. WEESE

RKT 6/26/01

OUTLINE & PERFORMANCE

SPECIFICATIONS

RESOLVER BRUSHLESS FRAMELESS

SCALE

Tolerancing Complies With ANSI/ASME Y14.5M-1994

CHG.

REVISIONS

DATE

APPR.

CHG.

REVISIONS

DATE

APPR.

CHG.

REVISIONS

DATE

APPR.

CHG.

ECO#D5852 3/02 RKT

APPROV

RKT 6/26/01

ECO#D5810 1/02 RKT

CODE IDENT NO.

REVISIONS

DATE

APPR.

58655

2:1

DWG.

NO.

31BRCX-300-B1/20 B

SHEET 1 OF 2
