NOTES:
1. MATERIAL:
BODY - ALUMINUM, TIN PLATED
SCREW - ALUMINUM, TIN PLATED
2. UL LISTED, CSA CERTIFIED, OR cULus FOR USE UP TO
600V & TEMPERATURE RATED 90 C (AL9CU)
C
E
C
F
D
B
A
G RAD
BOLT SIZE
BOLT SIZE
G RAD
B
A
F
D
3. DUAL RATED FOR USE WITH COPPER OR ALUMINUM
STRANDED CODE CONDUCTOR
4. THESE PARTS ARE RoHS COMPLIANT
5. USE OF OXIDE INHIBITING JOINT COMPOUND LIKE
PANDUIT CMP-100 RECOMMENDED FOR PAD TO PAD
AND CONDUCTOR SURFACES
6. SEE PACKAGING LABEL FOR TIGHTENING TORQUE
INFORMATION
7. PKG QTY:
6=6
W
FIGURE 1
L
OR
FIGURE 2
N
A
M
L
C
US
E
D
C
B
K
H
J
I
* HEX SIZE MAY DIFFER FROM CHART. DIFFERENCE IN SIZE WILL NOT AFFECT FIT, FORM, OR FUNCTION OF PART
TITLE
LAM2A SERIES
ALUMINUM MECHANICAL LUGS
CUSTOMER DRAWING
F
10N006AT/08
10N006AT-NC/08.SLDDRW
MATERIAL
ITEM REVISION NAME
DATASET FILE NAME
UNLESS OTHERWISE SPECIFIED,
DIMENSIONAL TOLERANCES ARE: IN [mm]
.X
.XXX
.XX
ANGLES
08
2/13
JHNU JHNU RGB
REVISED TITLE BLOCK
10N006AT-NC
THIRD ANGLE
PROJECTION
DRAWN BY
SEE NOTES
DRAWING NUMBER
10N006AT-NC
SIZE
REV
DATE
BY
CHK APR
DESCRIPTION
ECN
JHNU
DATE
2/06
CHK
JHNU
SCALE
NONE
SHEET 1 0F 1
B
F
