This document was generated on 02/08/2012
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0757580101
Active
ipass
0.80mm Pitch, iPass™ Dual Port Stacked I/O, External Application, Integrated Cage
and Connector Assembly, Right Angle, Press-Fit, 52 Circuit, 0.76µm Gold (Au) Plating
Documents:
3D Model
Drawing (PDF)
Product Specification PS-75586-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
I/O Connectors
75758
Wire-to-Board
I/O Plug Connector Subassembly
ipass
iPass™
N/A
EU RoHS
RoHS Compliant by
Exemption
REACH SVHC
Not Reviewed
Low-Halogen Status
Not Reviewed
China RoHS
General
Product Family
Series
Application
Component Type
Overview
Product Name
Type
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Gender
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Plating min - Mating
Polarized to Mating Part
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
52
52
Black
250
Male
None
Yes
Copper
Gold
Gold
High Temperature Thermoplastic
2
Right Angle
Yes
Yes
1.57mm
Tray
No
0.80mm
0.762µm
No
N/A
-40°C to +80°C
Through Hole
n/a
N/A
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
75758Series
Mates With
74548 iPass™ Cable Assembly
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Press-In Tool for
0622030200
iPass+™ Stacked
iPass+™ HD
0622030210
Removal Tool
Electrical
Current - Maximum per Contact
Shield Type
Shielded
0.5A
EMI Gasket
Yes
Material Info
Reference - Drawing Numbers
Product Specification
PS-75586-001
