This document was generated on 09/25/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
39-00-0283
Active
Standard .093" Pin and Socket Connectors
2.36mm Diameter, Standard .093" Pin and Socket Crimp Terminal, Series 1380, Male,
with Tin (Sn) over Copper Plated Brass Contact, 18-24 AWG, Reel
Documents:
Drawing (PDF)
Product Specification PS-1380-002 (PDF)
Product Specification PS-1380-003 (PDF)
RoHS Certificate of Compliance (PDF)
Series
image - Reference only
Crimp Terminals
1380
Power
Yes
Standard .093" Pin and Socket Connectors
Standard .093"
800753584839
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
General
Product Family
Series
Application
Crimp Quality Equipment
Overview
Product Name
UPC
Physical
Durability (mating cycles max)
Gender
Material - Metal
Material - Plating Mating
Material - Plating Termination
Net Weight
Packaging Type
Plating min - Mating
Plating min - Termination
Termination Interface: Style
Wire Insulation Diameter
Wire Size AWG
Wire Size mm²
25
Male
Brass
Tin
Tin
340.000/mg
Reel
0.889µm
0.889µm
Crimp or Compression
1.50-3.10mm
18, 20, 22, 24
N/A
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
1380Series
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Mini-Mac™
0638924000
Applicator
Extractor Tool
0638240200
for .093 and
HCS-125 Product
Series
Mini-Mac™
0638927000
Applicator
Terminator Die
0011402002
Japan
Description
Product #
Applicator for M211A 0011260069
Bench Press, 14-28
AWG Wire
Material Info
Old Part Number
1380T
Reference - Drawing Numbers
Product Specification
Sales Drawing
PS-1380-002, PS-1380-003, RPS-1380-001,
RPS-1380-002
SD-1380*
