AS85049/37 and M38999/8
90° EMI/RFI Non-Environmental Backshell
CONNECTOR DESIGNATOR:
F
MIL-DTL-38999 Series I and II
Finish
N
= Electroless Nickel
X
= Nickel Fluorocarbon Polymer
W
= 1,000 Hr. Cadmium Olive Drab
Z
= Zinc-Nickel, Black
over Electroless Nickel
M85049/37
TABLE I: Shell Size
10
Shell Size
(Table I)
W
03
L
D
= 3 Drain Holes
L
= Encapsulating
Hole
B
Shell Series I
Size Shell Size
Series II
Ref.
08
10
12
14
16
18
20
22
24
09
11
13
15
17
19
21
23
25
A Thread
Class 2B
.438 - 28 UNEF
.562 - 24 UNEF
.688 - 24 UNEF
.813 - 20 UNEF
.938 - 20 UNEF
1.063 - 18 UNEF
1.188 - 18 UNEF
1.313 - 18 UNEF
1.438 - 18 UNEF
C Dia
Max
.750
.850
1.000
1.100
1.250
1.400
1.500
1.650
1.750
(19.1)
(21.6)
(25.4)
(27.9)
(31.8)
(35.6)
(38.1)
(41.9)
(44.5)
Basic
Part Number
Clamp Size
(Table I)
TABLE II: Clamp Size and Dimensions
Series II
Shell
Size
8
10
12
14
16
18
20
22
24
Series I
Shell Size
Ref.
09
11
13
15
17
19
21
23
25
E
Max
.720
.720
.800
.850
.910
1.000
1.050
1.100
1.200
(18.3)
(18.3)
(20.3)
(21.6)
(23.1)
(25.4)
(26.7)
(27.9)
(30.5)
F
Max
2.50
2.50
2.56
2.69
2.81
3.03
3.19
3.31
3.31
(63.5)
(63.5)
(65.0)
(68.3)
(71.4)
(77.0)
(81.0)
(84.1)
(84.1)
Clamp Size
Min Max
01
01
02
02
02
03
03
03
04
02
03
04
05
06
06
07
08
09
TABLE II: Clamp Size and Dimensions
Clamp
Size
01
02
03
04
05
06
07
08
09
Cable Range
Min
Max
.062 (1.6)
.125 (3.2)
.125 (3.2)
.250 (6.4)
.250 (6.4)
.375 (9.5)
.312 (7.9)
.500 (12.7)
.437 (11.1)
.625 (15.9)
.562 (14.3)
.750 (19.1)
.687 (17.4)
.875 (22.2)
.812 (20.6) 1.000 (25.4)
.937 (23.8) 1.125 (28.6)
G
Max
.781
.969
1.062
1.156
1.250
1.375
1.500
1.625
1.750
(19.8)
(24.6)
(27.0)
(29.4)
(31.8)
(34.9)
(38.1)
(41.3)
(44.5)
APPLICATION NOTES
1.
2.
3.
For complete dimensions see the
applicable Military Specification.
Metric dimensions (mm) are in
parentheses.
Cable Range is defined as the
accommodation range for the wire
bundle or cable. Dimensions shown
are not intended for inspection
criteria.
© 2013 Glenair, Inc.
Dimensions in inches (millimeters) and are subject to change without notice.
Mil-Spec Backshells
U.S. CAGE Code 06324
Rev. 05.29.15
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
B-61
