FZTYL7E7EBAF300 Overview

Cable Assembly, 12 Conductor(s),

FZTYL7E7EBAF300 Parametric

Parameter Name	Attribute value
Maker	Panduit
Reach Compliance Code	compliant
Other features	STANDARD: ISO/IEC 11801
application	OPTIMIZE CABLE MANAGEMENT, SPEED DEPLOYMENT
Certification	ICEA; ISO/IEC; TIA; TIA/EIA
ConnectorSide1	PANMPO FEMALE
ConnectorSide2	PANMPO FEMALE
Connector bracket type	CABLE ASSEMBLY
diameter	4.5 mm
Number of conductors	12
Maximum operating temperature	70 °C
Minimum operating temperature
shield	NO
Base Number Matches	1

Preview

Download Datasheet

View All

QuickNet

™

PanMPO

™

Small Diameter

Trunk Cable Assemblies

technical information

PanMPO

™

Trunk Assemblies are pre-terminated 12-fiber and 24-fiber cable assemblies. The unique

design of the PanMPO

™

Connector allows for rapid gender and polarity change in the field, in support

of standards-compliant cable plant migration from 10G cassette-based systems to 40G MPO

connector-based parallel optics cable plant. These trunk cable assemblies optimize cable routing

requirements to ensure efficient use of pathway space and significantly reduce installation time and

cost. All small diameter trunk cable assemblies are factory terminated and tested to deliver verified

optical performance and reliability for improved network integrity. 10Gig versions provide 10 Gb/s

network performance up to 300 meters for OM3 and up to 550 meters for OM4 per IEEE 802.3ae

10 GbE standard while maintaining compatibility with legacy systems.

S P E C I F I C AT I O N S H E E T

application

10G fiber backbone or permanent link when mated to QuickNet

™

Cassettes or fiber adapter panels paired with MPO to LC breakout harnesses.

Method A and Method B TIA-568-C compliant for 40G parallel optics multimode applications. Allows system designers to tailor configuration,

reach and breakout construction to application requirements; to minimize waste, optimize cable management, speed deployment, improve

flexibility and manageability for lower installation costs. Small diameter trunk cable assemblies use 30 – 40% less space which is ideal for

high cable density applications.

construction

Cable type:

Cable

jacket ratings:

Fiber types:

Connector

types end ‘A’

and end ‘B’:

Fiber count:

Jacket color:

Indoor Small Diameter Trunk

Optical Fiber Nonconductive Plenum (OFNP)

Low Smoke Zero Halogen (LSZH)

Multimode:

OM3 50/125µm

OM4 50/125µm

physical properties

Cable outside diameter (OD):

Minimum bend radius:

Cable tensile strength:

Cable compressive load:

Flex:

12-fiber:

24-fiber:

30mm

12-fiber:

24-fiber:

10 N/mm

100 cycles at 4.9N

50N

500 mating cycles*

3.0mm

12-fiber:

24-fiber:

12-fiber:

24-fiber:

10mm

19mm

23mm

440N

660N

4.5mm

5.4mm

PanMPO

™

Female or PanMPO

™

Male

12 and 24

OM3:

OM4:

Aqua

Connector cable retention:

Connector durability:

Breakout outside diameter:

Transition outside diameter:

Pulling eye diameter:

Twist:

Breakout length:

Gender reversal durability:

Polarity reversal durability:

10 cycles at 15N

50 cycles

optical properties

Maximum cable

attenuation:

Maximum

connector

insertion loss

(per mated pair):

Minimum

connector

return loss:

Multimode:

Standard IL:

Optimized IL:

3.5dB/km at 850nm

1.5dB/km at 1300nm

0.50dB

0.35dB

environmental properties

Operating temperature:

Storage and

shipping temperature:

Installation temperature:

0°C to +70°C

-40°C to +70°C

-0°C to +60°C

Multimode:

OM3 30dB minimum

OM4 30dB minimum

standards

Meets or exceeds:

ISO/IEC 11801, TIA/EIA-568-C.3,

TIA-604-5 (FOCIS-5), TIA/EIA-568-C.1,

GR-409-CORE, ICEA S-83-596

RoHS Complaint

*With proper cleaning and inspection

w w w.pand uit.co m
