TECHNICAL DATA SHEET
1/2
RIGHT ANGLE RECEPTACLE FOR PCB
SMOOTH BORE - SOLDER TYPE
R222.680.700
Series :
SMP
All dimensions are in mm.
.
po
.
ao
COMPONENTS
BODY
CENTER CONTACT
OUTER CONTACT
INSULATOR
GASKET
OTHERS PARTS
-
-
MATERIALS
STAINLESS STEEL + BRASS
BERYLLIUM COPPER
PTFE
-
-
-
-
-
-
PLATINGS (
µm
)
PASSIVATED + GOLD 0.5 OVER NICKEL 2
GOLD 1.27 OVER NICKEL 1.27
Issue :0518
A
In the effort to improve our products, we reserve the right to make changes judged to be
necessary.
TECHNICAL DATA SHEET
2/2
RIGHT ANGLE RECEPTACLE FOR PCB
SMOOTH BORE - SOLDER TYPE
PACKAGING
Standard
100
Unit
‘W’ option
Other
Contact us
R222.680.700
Series :
SMP
SPECIFICATION
ELECTRICAL CHARACTERISTICS
Impedance
Frequency
VSWR
1.25
+
Insertion loss
RF leakage
-(
Voltage rating
Dielectric withstanding voltage
Insulation resistance
50
0-12
0.000
0.12
Ω
GHz
x F(GHz) Maxi
√F(GHz)
dB Maxi
- F(GHz)) dB Maxi
ENVIRONMENTAL
Operating temperature
Hermetic seal
Panel leakage
-65/+165
° C
NA
Atm.cm3/s
NA
335
Veff Maxi
500
Veff mini
5000
MΩ mini
OTHERS CHARACTERISTICS
Assembly instruction
Others :
Compliant with MIL-STD-348
MECHANICAL CHARACTERISTICS
Center contact retention
Axial force – Mating end
Axial force – Opposite end
Torque
Recommended torque
Mating
Panel nut
6.8
N mini
6.8
N mini
NA
N.cm mini
NA
N.cm
NA
N.cm
Mating life
Weight
1000
Cycles mini
0.366
g
Issue :0518
A
In the effort to improve our products, we reserve the right to make changes judged to be
necessary.
