YNV05T100xy DC-DC Converter Family Data Sheet
3.0-5.5 VDC Input; 0.9-3.3 VDC Output @ 10A
The
Features
Products: Y-Series
Applications
Intermediate Bus Architectures
Telecommunications
Data communications
Distributed Power Architectures
Servers, workstations
Benefits
High efficiency – no heat sink required
Reduces total solution board area
RoHS lead-free solder and lead-solder-exempted
products are available
No derating up to 85
C
Industry-standard footprint and pinout
Single-in-Line Package (SIP): 2.0” x 0.535” x 0.28”
(50.8 x 13.59 x 7.11 mm)
Weight: 0.26 oz [7.28 g]
Synchronous Buck Converter topology
Start-up into pre-biased output
No minimum load required
Output voltage trim +/-10% of Vout (-5% to +10% for
0.9 V output)
Operating ambient temperature: -40 °C to 85 °C
Remote output sense
Remote ON/OFF (Positive or Negative)
Fixed-frequency operation
Auto-reset output overcurrent protection
Auto-reset overtemperature protection
High reliability, MTBF = TBD million hours
All materials meet UL94, V-0 flammability rating
UL 60950 recognition in U.S. & Canada, and DEMKO
certification per IEC/EN 60950
Description
Power-One’s point-of-load converters are recommended for use with regulated bus converters in an
Intermediate Bus Architecture (IBA). The Y-Series YNV05T100XY non-isolated DC-DC converters deliver up
to 10 A of output current in an industry-standard through hole single in-line package (SIP). Operating from a
3.0 – 5.5V input, these converters are ideal choices for Intermediate Bus Architectures where point-of-load
power delivery is generally a requirement.
The YNV05T100XY converters are available in individual output voltage versions, allowing coverage of the
output voltage range from 0.9V to 3.3V. Each version is capable of providing an extremely tight, highly
regulated and trimmable output.
The YNV05T100XY converters provide exceptional thermal performance, even in high temperature
environments with minimal airflow. No derating is needed up to 85
C
under natural convection conditions.
This is accomplished through the use of circuitry, packaging, and processing techniques to achieve ultra-high
efficiency and excellent thermal management along with a very sleek body profile.
The sleek body profile and the preclusion of heat sinks minimize impedance to system airflow, thus enhancing
cooling for both upstream and downstream devices. The use of 100% automation for assembly, coupled with
advanced power electronics and thermal design, results in a product with extremely high reliability.
MCD10200 Rev. 1.1, 16-Jul-10
Page 1 of 26
www.power-one.com
YNV05T100xy DC-DC Converter Family Data Sheet
3.0-5.5 VDC Input; 0.9-3.3 VDC Output @ 10A
Electrical Specifications
Conditions: T
A
=25ºC, Airflow=200 LFM (1 m/s), Vin=5 VDC, Vout = 0.9 - 3.3V, unless otherwise specified.
PARAMETER
ABSOLUTE MAXIMUM RATINGS
Input Voltage
Operating Ambient Temperature
Storage Temperature
Continuous
NOTES
MIN
-0.3
-40
-55
TYP
MAX UNITS
6
85
125
VDC
°C
°C
kHz
+10
+10
0.5
%
%
VDC
ms
ms
ms
0.8
5.5
5.5
0.8
VDC
VDC
VDC
VDC
FEATURE CHARACTERISTICS
Switching Frequency
Output Voltage Trim Range
Remote Sense Compensation
Turn-On Delay Time
1
300
See Trim Equations on page 6 & 7
V
OUT
= 0.9 VDC
Full resistive load
From Vin = Vin(min) to Vo=0.1* Vo(nom)
From enable to Vo= 0.1*Vo(nom)
From 0.1*Vo(nom) to 0.9*Vo (nom)
2
-10
-5
With Vin = (Converter Enabled, then Vin applied)
With Enable (Vin = Vin(nom) applied, then enabled
Rise time (Full resistive load)
ON/OFF Control (Positive Logic)
Converter Off
Converter On
ON/OFF Control (Negative Logic)
Converter Off
Converter On
Note:
2
1
3.5
3.5
3.5
-5
2.4
2.4
-5
1. Note that start-up time is the sum of turn-on delay time and rise time.
2. The converter is on if ON/OFF pin is left open.
MCD10200 Rev. 1.1, 16-Jul-10
Page 2 of 26
www.power-one.com
YNV05T100xy DC-DC Converter Family Data Sheet
3.0-5.5 VDC Input; 0.9-3.3 VDC Output @ 10A
Electrical Specifications (continued)
Conditions: T
A
=25ºC, Airflow=200 LFM (1 m/s), Vin=5 VDC, Vout = 0.9 - 3.3V, unless otherwise specified.
PARAMETER
INPUT CHARACTERISTICS
Operating Input Voltage Range
Input Under Voltage Lockout
Turn-on Threshold
Turn-off Threshold
Maximum Input Current
Vin = 4.5V, Iout = 10A
Vin = 3.0V, Iout = 10A
Vin = 3.0V, Iout = 10A
Vin = 3.0V, Iout = 10A
Vin = 3.0V, Iout = 10A
Vin = 3.0V, Iout = 10A
Vin = 3.0V, Iout = 10A
Vin = 3.0V, Iout = 10A
Input Stand-by Current (Converter disabled)
Input No Load Current (Converter enabled)
V
OUT
= 3.3 VDC
V
OUT
= 2.5 VDC
V
OUT
= 2.0 VDC
V
OUT
= 1.8 VDC
V
OUT
= 1.5 VDC
V
OUT
= 1.2 VDC
V
OUT
= 1.0 VDC
V
OUT
= 0.9 VDC
Vin = 5.0 VDC
Vin = 5.5 VDC
V
OUT
= 3.3 VDC
V
OUT
= 2.5 VDC
V
OUT
= 2.0 VDC
V
OUT
= 1.8 VDC
V
OUT
= 1.5 VDC
V
OUT
= 1.2 VDC
V
OUT
= 1.0 VDC
Input Reflected-Ripple Current -
i
s
V
OUT
= 0.9 VDC
NOTES
For Vout
2.5V
For Vout
2.5V
MIN
4.5
3.0
TYP
5.0
5.0
2.05
MAX UNITS
5.5
5.5
2.15
VDC
VDC
VDC
VDC
7.8
9
7.3
6.7
5.7
4.7
4.0
3.6
ADC
ADC
ADC
ADC
ADC
ADC
ADC
ADC
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
P-P
1.75
1.9
10
90
85
80
75
70
65
60
60
15
See Fig. H for setup. (BW = 20 MHz)
MCD10200 Rev. 1.1, 16-Jul-10
Page 3 of 26
www.power-one.com
YNV05T100xy DC-DC Converter Family Data Sheet
3.0-5.5 VDC Input; 0.9-3.3 VDC Output @ 10A
Electrical Specifications (continued)
Conditions: T
A
=25ºC, Airflow=200 LFM (1 m/s), Vin=5 VDC, Vout = 0.9 - 3.3V, unless otherwise specified.
PARAMETER
OUTPUT CHARACTERISTICS
Output Voltage Set Point (no load)
Output Regulation
1
NOTES
MIN
-1.5
TYP
Vout
MAX UNITS
+1.5
%Vout
%Vout
%Vout
+3
%Vout
Over Line
Over Load
Output Voltage Tolerance
(Over all operating input voltage, resistive load
and temperature conditions until end of life )
Output Ripple and Noise - 20MHz bandwidth (Fig. H)
Peak-to-Peak
Peak-to-Peak
External Load Capacitance
Min ESR > 1mΩ
Min ESR > 10 mΩ
Output Current Range
Output Current Limit Inception (I
OUT
)
Output Short- Circuit Current (Hiccup mode)
Vin = 3.0V – 5.5V, Full resistive load
From no load to full load
-3
Over line, load and temperature
Vout = 3.3V Full load
Vout = 0.9V Full load
Plus full load (resistive)
0.2
0.4
40
20
70
40
1,000
5,000
mV
P-P
mV
P-P
μF
μF
A
A
Arms
0
15
Short=10 mΩ, continuous
Co = 100
μF
ceramic + 1
μF
ceramic
Co = 100
μF
ceramic + 1
μF
ceramic
Full load (5A)
V
OUT
= 3.3 VDC
V
OUT
= 2.5 VDC
V
OUT
= 2.0 VDC
V
OUT
= 1.8 VDC
V
OUT
= 1.5 VDC
V
OUT
= 1.2 VDC
V
OUT
= 1.0 VDC
V
OUT
= 0.9 VDC
95.5
93.5
92.0
91.5
90.0
88.5
86.5
85.0
3
120
40
125
40
2
2
10
18.5
DYNAMIC RESPONSE
Load current change from 5A – 10A, di/dt = 5 A/μS
Settling Time (V
OUT
< 10% peak deviation)
Unloading current change 10A – 5A, di/dt =-5 A/μS
Settling Time (V
OUT
< 10% peak deviation)
mV
µs
mV
µs
%
%
%
%
%
%
%
%
EFFICIENCY
Note:
1. Trim resistor connected across the GND (pin 5) and TRIM pins of the converter.
2.
See waveforms for dynamic response and settling time for different output voltages.
MCD10200 Rev. 1.1, 16-Jul-10
Page 4 of 26
www.power-one.com
YNV05T100xy DC-DC Converter Family Data Sheet
3.0-5.5 VDC Input; 0.9-3.3 VDC Output @ 10A
Operation
Input Voltage Ripple [mV]
160
140
120
100
80
60
40
20
0
0
1
2
Vout [V]
3
4
Vin=5.0V
Vin=3.3V
Input and Output Impedance
YNV05T100XY converters should be connected
via a low impedance to the DC power source. In
many applications, the inductance associated with
the distribution from the power source to the input
of the converter can affect the stability of the
converter. It is recommended to use decoupling
capacitors (minimum 47μF) placed as close as
possible to the converter input pins in order to
ensure stability of the converter and reduce input
ripple voltage. Internally, the converter has 52uF
(low ESR ceramics) of input capacitance.
In a typical application, low - ESR tantalum or
POS capacitors will be sufficient to provide
adequate ripple voltage filtering at the input of the
converter. However, very low ESR ceramic
capacitors 47μF-100μF are recommended at the
input of the converter in order to minimize the
input ripple voltage. They should be placed as
close as possible to the input pins of the converter.
The YNV05T100xy has been designed for stable
operation with or without external output
capacitance. Low ESR ceramic capacitors placed
as close as possible to the load (Min 47μF) are
recommended for improved transient performance
and lower output voltage ripple.
It is important to keep low resistance and low
inductance PCB traces when the connecting load
to the output pins of the converter in order to
maintain good load regulation.
Fig. B:
Input Voltage Ripple, C
IN
= 470
μF
polymer +
2x47
μF
ceramic
Fig. A shows input voltage ripple for various output
voltages using four 47μF input ceramic capacitors.
The same plot is shown in Fig. B with one 470μF
polymer capacitor (6TPB470M from Sanyo) in
parallel with two 47μF ceramic capacitors at full
load.
ON/OFF (Pin 10)
The ON/OFF pin is used to turn the converter on
or off remotely via a system signal. There are two
remote control options available, positive logic
(standard option) and negative logic, and both are
referenced to GND. Typical connections are
shown in Fig. C.
7,8
Vin
R*
10
Nex
-v
Series
Converter
TM
3
SENSE
1,2,4
ON/OFF
Vout
TRIM
9
Rload
Vin
140
Input Voltage Ripple [mV]
120
100
80
60
40
20
0
0
1
2
Vout [V]
3
4
Vin=5.0V
Vin=3.3V
CONTROL
INPUT
6
GND
GND
5
R* is for negative logic option only
Fig. C:
Circuit configuration for ON/OFF function.
The positive logic version turns the converter on
when the ON/OFF pin is at a logic high or left
open, and turns converter off when at a logic low
or shorted to GND.
Fig. A:
Input Voltage Ripple, C
IN
= 4x47
μF
ceramic.
MCD10200 Rev. 1.1, 16-Jul-10
Page 5 of 26
www.power-one.com
