DDZ9700T-7: DescriptionIMUs - Inertial Measurement Units Absolute Orientation 9-Axis Sensor; Categorysemiconductor Discrete semiconductor; File Size407KB，7 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet Parametric Compare View All

DDZ9700T-7 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	DDZ9700T-7	-	-	View	Buy Now

DDZ9700T-7 Overview

IMUs - Inertial Measurement Units Absolute Orientation 9-Axis Sensor

DDZ9700T-7 Parametric

Parameter Name	Attribute value
Product Category	Zener Diodes
Manufacturer	Diodes
RoHS	In Transition
Vz - Zener Voltage	13 V
Mounting Style	SMD/SMT
Package / Case	SOD-523-2
Pd - Power Dissipation	150 mW
Voltage Tolerance	5 %
Zener Current	50 nA
Minimum Operating Temperature	- 65 C
Maximum Operating Temperature	+ 150 C
Configuration	Single
Test Current	0.05 mA
Packaging	Reel
Packaging	MouseReel
Packaging	Cut Tape
Height	0.65 mm
Ir - Reverse Current	50 nA
Length	1.7 mm
Product	Zener Diode
Factory Pack Quantity	3000
Vf - Forward Voltage	0.9 V
Width	0.9 mm
Unit Weight	0.000035 oz

Preview

Download Datasheet

View All

DDZ9689T - DDZ9717T

SURFACE MOUNT ZENER DIODE

Features



Small, Low Profile Surface Mount Package

Very Sharp Breakdown Characteristics

Ideally Suited for Automated Assembly Processes

Very Low Leakage Current

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Mechanical Data



Case: SOD523

Case Material: Molded Plastic, “Green” Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020D

Terminal Connections: Cathode Band

Terminals: Finish - Matte Tin Annealed over Alloy 42 Leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.002 grams (Approximate)

Top View

Ordering Information

(Note 4)

Part Number

(Type Number)-7* (Note 5)

Case

SOD523

Packaging

3,000/Tape & Reel

*Example: The part number for the 6.2 Volt device would be DDZ9691T-7.

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and

Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.

Dispensed in every other cavity of the tape.

Marking Information

xx = Product Type Marking Code

(See Electrical Characteristics Table)

DDZ9689T - DDZ9717T

Document number: DS30553 Rev. 8 - 2

1 of 7

www.diodes.com

October 2017

DDZ9700T-7 Related Products

	DDZ9700T-7	DDZ9715T-7	DDZ9707T-7	DDZ9714T-7	DDZ9696T-7	DDZ9708T-7	DDZ9691T-7	DDZ9717T-7	DDZ9716T-7
Description	IMUs - Inertial Measurement Units Absolute Orientation 9-Axis Sensor	Zener Diodes 150MW 36V	Zener Diodes 150MW 20V	Zener Diodes 150MW 33V		Zener Diodes 150MW 22V	Zener Diodes 150MW 6.2V	Standard LEDs - SMD Red/Green	Precision Amplifiers 36V Precision Current Op Amp
Product Category	Zener Diodes	Zener Diodes	Zener Diodes	Zener Diodes	Zener Diodes	Zener Diodes	Zener Diodes	Zener Diodes	Zener Diodes
Manufacturer	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes	Diodes
RoHS	In Transition	Details	Details	Details	Details	Details	In Transition	Details	In Transition
Vz - Zener Voltage	13 V	36 V	20 V	33 V	9.1 V	22 V	6.2 V	43 V	39 V
Mounting Style	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT	SMD/SMT
Package / Case	SOD-523-2	SOD-523	SOD-523	SOD-523	SOD-523	SOD-523	SOD-523	SOD-523-2	SOD-523-2
Pd - Power Dissipation	150 mW	150 mW	150 mW	150 mW	150 mW	150 mW	150 mW	150 mW	150 mW
Voltage Tolerance	5 %	5 %	5 %	5 %	5 %	5 %	5 %	5 %	5 %
Minimum Operating Temperature	- 65 C	- 65 C	- 65 C	- 65 C	- 65 C	- 65 C	- 65 C	- 65 C	- 65 C
Maximum Operating Temperature	+ 150 C	+ 150 C	+ 150 C	+ 150 C	+ 150 C	+ 150 C	+ 150 C	+ 150 C	+ 150 C
Configuration	Single	Single	Single	Single	Single	Single	Single	Single	Single
Test Current	0.05 mA	0.05 mA	0.05 mA	0.05 mA	0.05 mA	0.05 mA	0.05 mA	50 uA	0.05 mA
Height	0.65 mm	0.7 mm	0.65 mm	0.7 mm	0.7 mm	0.7 mm	0.7 mm	0.65 mm	0.65 mm
Ir - Reverse Current	50 nA	50 nA	50 nA	50 nA	100 nA	50 nA	1 uA	50 nA	50 nA
Length	1.7 mm	1.3 mm	1.3 mm	1.3 mm	1.3 mm	1.3 mm	1.3 mm	1.7 mm	1.7 mm
Factory Pack Quantity	3000	3000	3000	3000	3000	3000	3000	3000	3000
Width	0.9 mm	0.9 mm	0.9 mm	0.9 mm	0.9 mm	0.9 mm	0.9 mm	0.9 mm	0.9 mm
Unit Weight	0.000035 oz	0.000035 oz	0.000035 oz	0.000035 oz	0.000035 oz	0.000035 oz	0.000035 oz	0.000035 oz	0.000035 oz
Packaging	Cut Tape	Reel	Reel	Cut Tape	Cut Tape	Cut Tape	Cut Tape	Cut Tape	Cut Tape
