Document 103-1
Chip Inductors – 1008LS (2520)
• Lower DCR than other 1008 inductors
• Ferrite construction for high current handling
• Inductance values: 1.0 – 100 µH
Part
number
1
Inductance
2
(µH)
1.0 @ 7.9 MHz
1.2 @ 7.9 MHz
1.5 @ 7.9 MHz
1.8 @ 7.9 MHz
2.2 @ 7.9 MHz
2.7 @ 7.9 MHz
3.3 @ 7.9 MHz
3.9 @ 7.9 MHz
4.3 @ 7.9 MHz
4.7 @ 7.9 MHz
5.0 @ 7.9 MHz
5.6 @ 7.9 MHz
6.2 @ 7.9 MHz
6.8 @ 7.9 MHz
8.2 @ 7.9 MHz
9.1 @ 7.9 MHz
10 @ 7.9 MHz
12 @ 2.5 MHz
15 @ 2.5 MHz
18 @ 2.5 MHz
22 @ 2.5 MHz
27 @ 2.5 MHz
33 @ 2.5 MHz
39 @ 2.5 MHz
47 @ 2.5 MHz
56 @ 2.5 MHz
68 @ 0.79 MHz
100 @ 0.79 MHz
Request free evaluation samples by contacting Coilcraft
or visiting
www.coilcraft.com.
SRF min
4
(MHz)
230
210
190
170
150
135
120
105
85
90
30
80
75
70
65
57
60
38
30
26
22
12
19
26
12
8.0
5.7
4.5
Percent
tolerance
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Q
min
3
DCR max
5
(Ohms)
0.62
0.68
0.76
0.84
1.10
1.28
1.46
1.56
1.70
1.68
2.20
1.82
2.50
2.00
2.65
2.90
2.95
3.30
3.70
4.00
6.14
6.45
7.00
10.0
10.7
10.0
13.5
20.5
Irms
6
(mA)
700
650
630
600
520
490
450
420
400
400
360
380
330
360
330
310
300
290
280
160
270
210
200
170
160
170
145
120
Color
code
7
Black
Red
Green
Gray
Red
Violet
Orange
White
Orange
Violet
Black
Blue
Red
Gray
Red
Brown
Black
Red
Green
Gray
Red
Violet
Orange
White
Violet
Blue
Gray
Black
1008LS-102XJL_
1008LS-122XJL_
1008LS-152XJL_
1008LS-182XJL_
1008LS-222XJL_
1008LS-272XJL_
1008LS-332XJL_
1008LS-392XJL_
1008LS-432XJL_
1008LS-472XJL_
1008LS-502XJL_
1008LS-562XJL_
1008LS-622XJL_
1008LS-682XJL_
1008LS-822XJL_
1008LS-912XJL_
1008LS-103XJL_
1008LS-123XJL_
1008LS-153XJL_
1008LS-183XJL_
1008LS-223XJL_
1008LS-273XJL_
1008LS-333XJL_
1008LS-393XJL_
1008LS-473XJL_
1008LS-563XJL_
1008LS-683XJL_
1008LS-104XJL_
48 @ 50 MHz
37 @ 50 MHz
37 @ 50 MHz
37 @ 50 MHz
37 @ 50 MHz
37 @ 50 MHz
37 @ 50 MHz
37 @ 7.9 MHz
30 @ 7.9 MHz
32 @ 7.9 MHz
25 @ 7.9 MHz
37 @ 7.9 MHz
32 @ 7.9 MHz
37 @ 7.9 MHz
37 @ 7.9 MHz
37 @ 7.9 MHz
37 @ 7.9 MHz
28 @ 2.5 MHz
34 @ 2.5 MHz
28 @ 2.5 MHz
20 @ 2.5 MHz
24 @ 2.5 MHz
22 @ 2.5 MHz
33 @ 2.5 MHz
20 @ 2.5 MHz
20 @ 2.5 MHz
14 @ 0.79 MHz
13 @ 0.79 MHz
1. When ordering, please specify
termination
and
packaging
codes:
1008LS-103XJLC
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
E
= Halogen free component. RoHS compliant silver-
palladium-platinum-glass frit terminations.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5)
or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (7500 parts per
full reel).
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/
HP 4286A impedance analyzer with Coilcraft-provided correlation pieces.
3. Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test
fixture.
4. SRF measured using an Agilent/HP 8753D network analyzer with a
Coilcraft SMD-D fixture.
5. DCR measured on a Cambridge Technology Micro-ohmmeter.
6. Current that causes a 15°C temperature rise from 25°C. Because of
their open construction, these parts will not saturate.
7. Current production parts are marked with one dot. Prior production parts
were marked with three dots. Part marking does not indicate polarity.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Designer’s Kit C336
contains 10 of each stocked value
Core material
Ceramic/Ferrite
Environmental
RoHS compliant, halogen free optional
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
38.3 – 41.0 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+100°C with derated current
Storage temperature
Component: –40°C to +100°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+100 to +350 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Packaging
2000/7″ reel Plastic tape: 8 mm wide, 0.3 mm thick,
4 mm pocket spacing, 2.0 mm pocket depth
PCB washing
Tested with pure water or alcohol only. For other
solvents, see Doc787_PCB_Washing.pdf
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 103-1
Revised 01/21/13
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 103-2
1008LS Series (2520)
Typical Q vs Frequency
50
40
Typical L vs Frequency
1000
1.8 µH
68 µH
Inductance (µH)
100
Q Factor
30
10 µH
33 µH
6.8 µH
33 µH
10 µH
6.8 µH
10
20
68 µH
10
1.8 µH
0
1
10
100
1
1
10
100
1000
Frequency (MHz)
Frequency (MHz)
B
overall
F
A
G
F
E
terminal
C
D
Pick and
place
material
I
J
I
Terminal wraparound:
approx 0.010/0,25 both ends
H
Recommended
Land Pattern
H
0.100
2,54
I
0.040
1,02
J
0.050 inches
1,27 mm
A
max
0.115
2,92
B
max
0.110
2,79
C
max
0.080
2,03
D
ref
0.020
0,51
E
0.080
2,03
F
0.020
0,51
G
0.060
1,52
Note:
Height dimension is before optional solder application. For maximum height
dimension including solder, add 0.006 in / 0,152 mm.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 103-2
Revised 01/21/13
© Coilcraft Inc. 2013
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
