ZFKDSA 1,5C-5,0- 7 GY - 1708634
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB terminal block, Nominal current: 16 A, Nom. voltage: 400 V, Connection method: Spring-cage
connection, Mounting: Wave soldering, Conductor/PCB connection direction: 45 °, Color: gray
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
Note
4055626010298
85369010
Made to Order (non-returnable)
50 STK
Technical data
Dimensions
Length
Dimension a
Constructional height
Length of the solder pin
Pin dimensions
Pin spacing
Hole diameter
14.1 mm
30 mm
13 mm
3.5 mm
0,7 x 0,7
5.08 mm
1.1 mm
General
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
Solder pin surface
Internal cylindrical gage
Stripping length
4 kV
4 kV
4 kV
250 V
400 V
630 V
EN-VDE
16 A
1.5 mm²
Sn
A1
7 mm
11/14/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/1708634
ZFKDSA 1,5C-5,0- 7 GY - 1708634
Technical data
Connection data
Conductor cross section AWG min.
Conductor cross section AWG max.
24
14
Standards and Regulations
Connection in acc. with standard
EN-VDE
Environmental Product Compliance
China RoHS
Environmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
Approvals
Approvals
Approvals
UL Recognized / cUL Recognized / EAC / cULus Recognized
Ex Approvals
Approval details
UL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
26-12
10 A
250 V
D
26-12
10 A
300 V
cUL Recognized
mm²/AWG/kcmil
Nominal current IN
Nominal voltage UN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm FILE E 60425
B
26-12
10 A
250 V
D
26-12
10 A
300 V
EAC B.01742
11/14/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/1708634
ZFKDSA 1,5C-5,0- 7 GY - 1708634
Approvals
cULus Recognized
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
