S-1711 Series
www.sii-ic.com
SUPER-SMALL PACKAGE 2-CIRCUIT HIGH RIPPLE-REJECTION
LOW DROPOUT CMOS VOLTAGE REGULATOR
Rev.3.1
_01
© SII Semiconductor Corporation, 2004-2015
The S-1711 Series is a 2-channel positive voltage regulator with a low dropout voltage, high-accuracy output voltage, and
low current consumption (150 mA output current) developed based on CMOS technology.
A 1.0
μF
small ceramic capacitor can be used, and a 2-circuit voltage regulator with
±1.0%
high-accuracy output voltage is
incorporated in SOT-23-6 or super-small SNT-6A package. A/ B/ E/ F type is provided with a discharge shunt function
allowing high-speed output response when the ON/OFF pin is used.
Compared with the conventional 150 mA output current 2-channel CMOS voltage regulators, high-density mounting is
realized by using super-small SNT-6A package and a small ceramic capacitor. Also, the low current consumption makes
the S-1711 Series ideal for mobile devices.
Features
1.5 V to 5.5 V, selectable in 0.1 V step
2.0 V to 6.5 V
±1.0%
200 mV typ. (3.0 V output product, I
OUT
= 150 mA)
During operation:
70
μA
typ., 90
μA
max. (Per circuit)
During power-off:
0.1
μA
typ., 1.0
μA
max.
Possible to output 150 mA (V
IN
≥
V
OUT(S)
+
1.0 V)
*1
(Per circuit)
•
Output current:
•
Input and output capacitors:
A ceramic capacitor of 1.0
μF
or more can be used.
•
Ripple rejection:
70 dB typ. (f = 1.0 kHz)
•
Built-in overcurrent protection circuit: Limits overcurrent of output transistor.
•
Built-in ON/OFF circuit:
Ensures long battery life.
•
Pull-up or pull-down resistor is selectable.
•
Discharge shunt function is selectable.
•
Operation temperature range:
Ta =
−40°C
to
+85°C
*2
•
Lead-free, Sn 100%, halogen-free
*1.
Attention should be paid to the power dissipation of the package when the output current is large.
*2.
Refer to “
Product Name Structure”
for details.
•
Output voltage:
•
Input voltage:
•
Output voltage accuracy:
•
Dropout voltage:
•
Current consumption:
Applications
•
Constant-voltage power supply for cellular phone
•
Constant-voltage power supply for battery-powered device
•
Constant-voltage power supply for home electric/electronic appliance
Packages
•
SNT-6A
•
SOT-23-6
1
