RF Manual 15 edition
th
Application and design manual
for High Performance RF products
May 2011
High Performance RF for the most demanding applications
NXP’s RF Manual makes
design work much easier
NXP's RF Manual is one of the most important reference tools on the market for
today’s RF designers. It features our complete range of RF products, from low- to
high-power signal conditioning and high-speed data converters.
High Performance RF for the most demanding applications
When it comes to the most demanding RF applications, the first thing on the designer's mind is to meet the specified
performance. So that is exactly what NXP enables you to do, with the added benefits of silicon-based, volume
manufacturing process technologies. That means you can design your systems to the highest specifications, while still
retaining potential trade-offs with respect to efficiency, power, ruggedness, consistency, and integration levels.
Shipping more than four billion RF products annually, NXP is a clear industry leader in High Performance RF. From
satellite receivers, cellular base stations, and broadcast transmitters to ISM (Industrial, Scientific, and Medical) and
aerospace and defense applications, you will find the High Performance RF products you need at NXP. And constant
innovation ensures you always have the most effective solutions at your fingertips – whether it's innovative Doherty
power amplifier architectures, JESD204A CGV
TM
serialized data interfaces, or tiny GPS LNAs.
So if you're looking to improve your RF performance, design a highly efficient signal chain, or break new ground with an
innovative ISM application, then NXP's creative thinking and expert support can help you every step of the way.
High Performance RF design challenge
The day-to-day work offers many challenges to the RF designer, from the high diversity of signals to integration, or simply
the time spent. We recently started a design challenge (www.hprf-design-challenge.nxp.com). It offers a forum for RF
enthusiasts to walk with us through the steps of a design, from concept to prototype. This is, in essence, the goal of the
RF Manual – to make design work easier.
What’s new?
This RF Manual provides updated information on RF applications clustered in different segments. The segments are as
follows: wireless and broadband communication infrastructure, TV and satellite, portable devices, automotive, ISM, and
aerospace and defense.
We describe in detail the new developments in our core technologies, QUBiC4 and LDMOS. We have also added GaN
technology to our product offering; this key technology lets high-power amplifiers deliver very high efficiency in next
generation wireless communication systems.
4
NXP Semiconductors RF Manual 15
th
edition
New products include GaN power amplifiers, a complete line of overmolded plastic (OMP) RF power transistors and MMICs, and
our eighth generation LDMOS transistors (Gen8). Next-generation devices and improved products include GPS LNAs, medium
power amplifiers, IF gain blocks, LO generators, satellite LNB ICs, and CATV modules.
Our portfolio for the wireless communication infrastructure has expanded, with a comprehensive set of best-in-class Doherty
amplifier designs, a broad selection of amplifiers (medium power, variable gain, low noise), mixers, IQ modulators, and our
JESD204A-compliant, high-speed DACs and ADCs.
“I’m proud to present the 15
th
edition of our RF Manual. It covers NXP’s entire range of RF products and solutions in one
comprehensive catalog, and I’m convinced that you’ll find this version the most compelling and useful yet.”
Kind regards,
John Croteau
Sr. Vice President & General Manager
Business Line High Performance RF
RF Manual web page
www.nxp.com/rfmanual
