GDZ2V7LP3 - GDZ24LP3
ULTRA-SMALL LEADLESS
SURFACE MOUNT ZENER DIODE
Features
Ultra-Small Leadless Surface Mount Package (0.6 x 0.3mm)
Ultra-Low Profile Package (0.3mm)
Ideally Suited for Automated Assembly Processes
Low Leakage Current, Suitable for Battery-Powered Applications
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
Case: X3-DFN0603-2
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: Cathode Bar
Terminals: Finish
Matte
Tin over Copper Leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 0.2 mg (Approximate)
ADVANCE INFORMATION
X3-DFN0603-2
Top View
Bottom View
1
Cathode
2
Anode
Ordering Information
(Note 4)
Part Number
(Type Number)-7*
Notes:
Case
X3-DFN0603-2
Packaging
10,000/Tape & Reel
*Add “-7” to the appropriate type number in Electrical Characteristics Table. Example: 6.2V Zener = GDZ6V2LP3-7.
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4.
For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
Pin 1
xx = Product Type Marking Code
(See Electrical Characteristics Table)
Line Denotes Cathode Side
GDZ2V7LP3 - GDZ24LP3
Document number: DS35065 Rev. 18 – 2
1 of 5
www.diodes.com
September 2017
© Diodes Incorporated
GDZ2V7LP3 - GDZ24LP3
Thermal Characteristics
Characteristic
Power Dissipation (Note 5)
T
A
= +25°C
Thermal Resistance, Junction to Ambient Air (Note 5) T
A
= +25°C
Operating and Storage Temperature Range
Symbol
P
D
R
θJA
T
J,
T
STG
Value
250
500
-55 to +150
Unit
mW
C/W
C
ADVANCE INFORMATION
Electrical Characteristics
Type
Number
Marking
Code
(@T
A
= +25°C, unless otherwise specified.)
Zener Voltage Range
(Note 6)
V
Z
@ I
ZT
I
ZT
Max (V)
2.84
3.15
3.47
3.79
4.160
4.37
4.53
4.900
5.370
5.920
6.324
6.530
7.140
7.840
8.640
9.56
10.50
11.55
12.60
13.65
15.75
16.80
18.90
21.00
23.10
25.20
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Typical (µA)
-
-
-
-
-
-
-
-
-
-
90
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
I
R
Max (µA)
20
10
10
10
5
5.0
5.0
2.0
0.2
1.0
175
1.0
1.0
0.5
0.5
0.5
0.5
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
Reverse
Current
(Note 6)
@ V
R
V
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.5
4.75
2.8
3.0
3.5
4.0
5.0
6.0
7.0
8.0
8.0
8.0
10.5
11.2
12.6
14.0
15.4
16.8
Nom (V)
GDZ2V7LP3
GDZ3V0LP3
GDZ3V3LP3
GDZ3V6LP3
GDZ3V9LP3
GDZ4V1LP3
GDZ4V3LP3
GDZ4V7LP3
GDZ5V1LP3
GDZ5V6LP3
GDZ6V0LP3
GDZ6V2LP3
GDZ6V8LP3
GDZ7V5LP3
GDZ8V2LP3
GDZ9V1LP3
GDZ10LP3
GDZ11LP3
GDZ12LP3
GDZ13LP3
GDZ15LP3
GDZ16LP3
GDZ18LP3
GDZ20LP3
GDZ22LP3
GDZ24LP3
Notes:
Min (V)
2.57
2.85
3.14
3.41
3.740
3.93
4.08
4.420
4.840
5.310
5.676
5.860
6.470
7.060
7.760
8.65
9.50
10.45
11.40
12.35
14.25
15.20
17.10
19.00
20.90
22.80
JB
JC
JD
KU
KJ
KY
KK
KL
KM
KN
KW
KO
KT
KQ
KX
JE
JF
JG
JH
JI
JJ
JK
JL
JM
JN
JO
2.7
3.0
3.3
3.6
3.9
4.1
4.3
4.7
5.1
5.6
6.0
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
5. Device mounted on FR-4 PCB with minimum recommended pad layout, as shown in Diodes Incorporated’s Suggested Pad Layout document, which can
be found on our website at http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
GDZ2V7LP3 - GDZ24LP3
Document number: DS35065 Rev. 18 – 2
2 of 5
www.diodes.com
September 2017
© Diodes Incorporated
GDZ2V7LP3 - GDZ24LP3
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
0.30
1,000
0.25
P
D
, POWER DISSIPATION (W)
Note 5
100
0.20
10
T
A
= 150°C
ADVANCE INFORMATION
0.15
1
T
A
= 125°C
T
A
= 85°C
T
A
= 50°C
T
A
= 25°C
T
A
= -55°C
0.10
0.05
0.1
0
0
25
50
75
100
125
T
A
, AMBIENT TEMPERATURE (°C)
Figure 1 Power Derating Curve
150
0.01
0.2
0.4
0.6
0.8
1.0
1.2
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Figure 2 Typical Forward Characteristics
20
20
GDZ2V7LP3-7
GDZ6V2LP3-7
GDZ6V8LP3-7
Iz, ZENER CURRENT (mA)
15
Iz, ZENER CURRENT (mA)
GDZ3V0LP3-7
GDZ3V6LP3-7
GDZ3V9LP3-7
15
GDZ7V5LP3-7
GDZ8V2LP3-7
10
GDZ4V1LP3-7
GDZ4V3LP3-7
10
GDZ12LP3-7
GDZ15LP3-7
5
GDZ4V7LP3-7
GDZ5V1LP3-7
5
GDZ16LP3-7
GDZ22LP3-7
GDZ24LP3-7
0
2
3
4
5
Vz, ZENER VOLTAGE (V)
Figure 3 Typical Zener Breakdown Characteristics,
GDZ2V7LP3 – GDZ5V1LP3
0
1
6
0
5
15
20
25
30
Vz, ZENER VOLTAGE (V)
Figure 4 Typical Zener Breakdown Characteristics,
GDZ6V2LP3 – GDZ24LP3
10
I
R
, INSTANTANEOUS REVERSE CURRENT (nA)
100
20
f = 1MHz
C
T
, TOTAL CAPACITANCE (pF)
3 of 5
www.diodes.com
15
10
T
A
= 50°C
10
T
A
= 25°C
5
1
1.5
2
2.5
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Figure 5 Typical Reverse Characteristics - GDZ5V1LP3
0
0
1
2
3
4
5
V
R
, REVERSE VOLTAGE (V)
Figure 6 Typical Total Capacitance – GDZ5V1LP3
GDZ2V7LP3 - GDZ24LP3
Document number: DS35065 Rev. 18 – 2
September 2017
© Diodes Incorporated
GDZ2V7LP3 - GDZ24LP3
Package Outline Dimensions
Please see http://www.diodes.com/package-outlines.html for the latest version.
ADVANCE INFORMATION
A
A1 (2x)
D
e
E
b (2x)
X3-DFN0603-2
Dim
Min
Max
Typ
A
0.27
0.35
0.30
A1
0.00
0.03
0.02
b
0.19
0.29
0.24
D
0.595 0.645
0.62
E
0.295 0.345
0.32
e
-
-
0.355
L
0.14
0.24
0.19
All Dimensions in mm
L (2x)
Suggested Pad Layout
Please see http://www.diodes.com/package-outlines.html for the latest version.
X1
X
Dimensions
C
X
X1
Y
Y
Value
(in mm)
0.380
0.230
0.610
0.300
C
GDZ2V7LP3 - GDZ24LP3
Document number: DS35065 Rev. 18 – 2
4 of 5
www.diodes.com
September 2017
© Diodes Incorporated
GDZ2V7LP3 - GDZ24LP3
