FUJITSU TAKAMISAWA
CONNECTOR CATALOG
FOR BOARD-TO-BOARD CONNECTION
228 SERIES (CARD EDGE TYPE)
s
FEATURES
• 1.27 mm (0.050 in.) pitch contact arrangement in two
rows enables high-density mounting.
• Standard types with 30 to 120 contacts, S types with
112, 132, and 182 contacts, SMT types with 26, 40,
50, 60, and 100 contacts are available for various
purposes.
• Double side separated connection for 1.6 mm (0.063
in.) PC board
• Tails are spaced in a four-row staggered arrangement
(2.54 mm
×
1.905 mm) (0.100 in.
×
0.075 in.) for easy
PC board design.
• Insulation is UL-approved (94V-0) and is washable.
NO
s
SPECIFICATIONS
Item
Operating temperature range
Current rating
Voltage rating
Contact resistance
Insulation resistance
Dielectric withstand voltage
Insertion force
Withdrawal force
OR
DE
NE
SI
GN
W
S
Specifications
TF
s
MATERIALS
Item
Insulator
–55°C to +105°C
DC 2 A
Materials
AC 250 V
Polyester (UL94V-0)
Copper alloy
Contact
35 mΩ max. (DC 6 V, 0.1 A)
1000 MΩ min. (DC 500 V)
AC 500 V for 1 minute
Standard type
SMT type
S type
Conductor
Plating
Gold plating
Terminal
Palladium plating
2 kg max. (10 pins)
1 kg max. (10 pins)
Standard type
SMT type
S type
250 g min. (10 pins)
50 g min. (10 pins)
Applicable PC board
(standard)
Mounting through hole: 0.8 to 1.6
mm (0.031 to 0.063 in.)
Mating card edge: 1.6 mm (0.063
in.)
1
228 Series (Card Edge Type)
s
ORDERING CODE
FCN-22 4 J 050-G / 0 S
S type
With mounting flanges (no mounting flanges for S types)
Plating
G: Gold plating
Number of contacts
Standard: 30, 34, 40, 50, 60, 62, 80, 100, and 120
S type: 112, 132, and 182
SMT type: 26, 40, 50, 60, and 100
Body
J: Socket
4: Straight
5: Right-angle
8: SMT
NO
s
APPLICATIONS
Tail type
TF
OR
DE
NE
SI
GN
W
S
Fujitsu connector
220 series connector
(Card edge connector)
FCN-228J
-G/0-01
2
228 Series (Card Edge Type)
SMT TYPE (STRADDLE MOUNT)
s
DIMENSIONS
A
B
C
End terminal
1.27 (.050 )
No. 2
1.8
(0.070)
8
(0.315 )
1.2
(.047 )
2.69
(0.105 )
0.4 (0.015)
3.3
(0.129 )
13.2 (0.519)
11 (0.433)
NO
1
4-
No. 1
No. 3
1.8
(0.070)
R
D
s
PC BOARD PATTERN
(Component side)
-26, 40, 50, 60 and 100 contacts
Solder side : End terminal
Solder side : No. 2
0.8
±0.05
(.031
±0.001
)
1.27
±0.01
(.050
±0.004
)
C
±0.1
(±0.004)
No. 1
8.5 mm
(0.335 in.) min.
TF
OR
DE
NE
SI
GN
W
S
2.69
(0.105 )
1.4
(0.055)
1.4 mm
(0.055 in.) max.
5 mm
(0.197 in.) max.
7.2
(0.283)
Unit: mm (in.)
s
MATING PC BOARD CARD EDGE PATTERN
(Component side)
C
±0.1
(±0.004)
7 mm
(0.276 in.) min.
1.27
±0.05
(.050
±0.004
)
0.5
(0.019)
No. 3
(0
0.8
±0.05
(.031
±0.001
)
E
±0.1
(±0.004)
2
–
C
0
.0
.5
78
–
2
0.
01
9
–C
0.
5
9
)
C
Thickness of applicable PC board : 1.6 mm (0.06 in.)
)
(0
.0
78
–C
0
1
.0
1.6
±0.15
(.062
±0.005
)
Unit: mm (in.)
Unit: mm (in.)
s
PART NUMBERS AND DIMENSIONS
Number of
contacts
26
40
50
60
100
Part number
FCN-228J026-G/0-01
FCN-228J040-G/0-01
FCN-228J050-G/0-01
FCN-228J060-G/0-01
FCN-228J100-G/0-01
A
23.59 (0.928)
32.48 (1.278)
38.83 (1.528)
45.18 (1.778)
70.58 (2.778)
B
17.78 (0.700)
26.67 (1.050)
33.02 (1.300)
39.37 (1.550)
64.77 (2.550)
Dimensions: mm (in.)
C
15.24 (0.600)
24.13 (0.950)
30.48 (1.200)
36.83 (1.450)
62.23 (2.450)
D
19.71 (0.775)
28.60 (1.125)
34.95 (1.375)
41.30 (1.625)
66.70 (2.625)
E
17.58 (0.692)
26.47 (1.042)
32.82 (1.292)
39.17 (1.542)
64.57 (2.542)
3
228 Series (Card Edge Type)
