SPECIFICATION CONTROL DRAWING
Product Revisions
Product
Name
CWT-3
CWT-5
CWT-6
CWT-7
CWT-9
CWT-11
CWT-13
D
F
A
F
A
E
A
Product Dimensions
Ø
A
Ø
B
L
min
min
max
2.50
[0.098]
4.30
[0.170]
6.00
[0.236]
6.80
[0.268]
8.70
[0.343]
10.80
[0.425]
13.00
[0.512]
3.00
[0.118]
4.80
[0.189]
6.70
[0.264]
7.30
[0.287]
9.20
[0.362]
11.50
[0.453]
15.10
[0.594]
24.5
[0.965]
29.3
[1.154]
32.00
[1.260]
32.50
[1.280]
35.50
[1.398]
35.50
[1.398]
45.50
[1.791]
Ø
D
Ø
E
max
3.00
[0.118]
4.80
[0.189]
6.70
[0.264]
7.30
[0.287]
9.20
[0.362]
11.50
[0.453]
15.10
[0.594]
min
1.50
[0.060]
2.00
[0.079]
3.30
[0.130]
3.30
[0.130]
4.50
[0.177]
4.50
[0.177]
7.00
[0.276]
Prepared Cable Dimensions
Ø
F
Ø
G
H
min
max
1.00
[0.040]
1.50
[0.059]
2.80
[0.110]
2.80
[0.110]
4.00
[0.157]
4.00
[0.157]
6.50
[0.256]
2.50
[0.098]
4.30
[0.170]
6.00
[0.236]
6.80
[0.268]
8.70
[0.343]
10.80
[0.425]
13.00
[0.512]
6.0
0.5
[0.236±0.020]
8.0
0.5
[0.315±0.020]
9.0
0.5
[0.354±0.020]
10.0
1.0
[0.394±0.040]
11.0
1.0
[0.433±0.040]
12.0
1.0
[0.472±0.040]
16.0
1.0
[0.630±0.040]
J
7.0
0.5
[0.726±0.020]
9.0
0.5
[0.354±0.020]
10.0
0.5
[0.394±0.020]
11.0
1.0
[0.433±0.040]
12.0
1.0
[0.472±0.040]
13.0
1.0
[0.512±0.040]
17.0
1.0
[0.670±0.040]
MATERIALS
1. INSULATION SLEEVE: Heat-shrinkable, radiation cross-linked modified polyolefin. Color: transparent clear.
2. SOLDER PREFORM WITH FLUX:
SOLDER: TYPE Cd18 per ANSI/J-STD-006.
FLUX:
TYPE ROM1 per ANSI/J-STD-004.
3. MELTABLE SEALING RING: Thermally stabilized thermoplastic. Color: blue (size 3, 5, 6, 7, 9, 11); natural (size 13)
4. MELTABLE SEALING RING: Thermally stabilized thermoplastic. Color: blue (size 3, 5, 7, 11); gray (size 6); natural (size 9, 13)
APPLICATION
1. These controlled soldering devices are designed for termination of a bare or tin-plated copper shield on a cable having an
insulation rated for at least +85C, meeting the dimensional criteria listed in the table above.
2. Temperature range: -55C to +125C.
3. When installed properly, it will meet the requirements of TE Connectivity / Raychem Specification RT-1404.
4. For installation procedure and application equipment consult TE Connectivity / Raychem document RPIP-824-00.
For best results, prepare the cable as shown:
TITLE:
TE Connectivity
300 Constitution Drive,
Menlo Park, CA. 94025, U.S.A.
Unless otherwise specified dimensions are in millimeters.
[Inches dimensions are shown in brackets]
TOLERANCES:
0.00 N/A
0.0 N/A
0 N/A
PREPARED BY:
ANGLES: N/A
ROUGHNESS IN
MICRON
Raychem
DOCUMENT NO.:
Soldersleeve Shield
Terminator
CWT-XX
PROD. REV.:
DOC. ISSUE:
DATE:
TE Connectivity reserves the right to amend
this drawing at any time. Users should evaluate
the suitability of the product for their
application.
REPLACES:
See Table
DCR NUMBER:
4
SCALE:
SIZE:
15-Apr-11
SHEET:
CAGE CODE :
mforonda
06090
D020508
D040057
---
A
1 of 1
Print Date: 9-May-11
© 2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company. All Rights Reserved.
If this document is printed it becomes uncontrolled. Check with the web for the latest revision.
