BFG310-XR-T-R

Description
RF Bipolar Transistors TAPE-7 TNS-RFSS
Categorysemiconductor    Discrete semiconductor
File Size189KB,14 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Download Datasheet Parametric View All

BFG310-XR-T-R Online Shopping

Suppliers Part Number Price MOQ In stock
BFG310-XR-T-R - - View Buy Now

BFG310-XR-T-R Overview

RF Bipolar Transistors TAPE-7 TNS-RFSS

BFG310-XR-T-R Parametric

Parameter NameAttribute value
Product CategoryRF Bipolar Transistors
ManufacturerNXP
RoHSDetails
Transistor TypeBipolar
TechnologySi
Transistor PolarityNPN
DC Collector/Base Gain hfe Min60
Collector- Emitter Voltage VCEO Max6 V
Emitter- Base Voltage VEBO2 V
Continuous Collector Current0.01 A
Maximum Operating Temperature+ 150 C
ConfigurationSingle
Mounting StyleSMD/SMT
Package / CaseSOT-143
PackagingReel
Collector- Base Voltage VCBO15 V
DC Current Gain hFE Max60
Height1 mm
Length3 mm
Operating Frequency14000 MHz
Pd - Power Dissipation60 mW
Factory Pack Quantity3000
TypeRF Bipolar Small Signal
Width1.4 mm
BFG310/XR
NPN 14 GHz wideband transistor
Rev. 2 — 15 September 2011
Product data sheet
1. Product profile
1.1 General description
NPN silicon planar epitaxial transistor in a 4-pin dual-emitter SOT143R plastic package.
1.2 Features and benefits
High power gain
Low noise figure
High transition frequency
Gold metallization ensures excellent reliability
1.3 Applications
Intended for Radio Frequency (RF) front end applications in the GHz range, such as:
analog and digital cellular telephones
cordless telephones (Cordless Telephone (CT), Personal Communication
Network (PCN), Digital Enhanced Cordless Telecommunications (DECT), etc.)
radar detectors
pagers
Satellite Antenna TeleVision (SATV) tuners
repeater amplifiers in fiber-optic systems
1.4 Quick reference data
Table 1.
V
CBO
V
CEO
I
C
P
tot
h
FE
C
CBS
f
T
Quick reference data
Conditions
open emitter
open base
T
sp
145
C
I
C
= 5 mA; V
CE
= 3 V;
T
j
= 25
C
V
CB
= 5 V; f = 1 MHz;
emitter grounded
I
C
= 5 mA; V
CE
= 3 V;
f = 1 GHz; T
amb
= 25
C
[1]
Symbol Parameter
collector-base voltage
collector-emitter voltage
collector current (DC)
total power dissipation
DC current gain
collector-base
capacitance
transition frequency
Min
-
-
-
-
60
-
-
Typ
-
-
-
-
100
0.17
14
Max
15
6
10
60
200
0.3
-
Unit
V
V
mA
mW
pF
GHz
