FQD7P06 P-Channel QFET
®
MOSFET
April 2013
FQD7P06
P-Channel QFET
®
MOSFET
- 60 V, - 5.4 A, 450 m
Description
This P-Channel enhancement mode power MOSFET is
produced using Fairchild Semiconductor
®
’s proprietary
planar stripe and DMOS technology. This advanced
MOSFET technology has been especially tailored to reduce
on-state resistance, and to provide superior switching
performance and high avalanche energy strength. These
devices are suitable for switched mode power supplies,
audio amplifier, DC motor control, and variable switching
power applications.
D
G
G
S
Features
• - 5.4 A, - 60 V, R
DS(on)
= 450 m (Max.) @ V
GS
= - 10 V,
I
D
= - 2.7 A
• Low Gate Charge (Typ. 6.3 nC)
• Low Crss (Typ. 25 pF)
• 100% Avalanche Tested
S
●
●
▶ ▲
●
D-PAK
D
Absolute Maximum Ratings
Symbol
V
DSS
I
D
I
DM
V
GSS
E
AS
I
AR
E
AR
dv/dt
P
D
T
C
= 25°C unless otherwise noted
Parameter
Drain-Source Voltage
- Continuous (T
C
= 25°C)
Drain Current
- Continuous (T
C
= 100°C)
Drain Current
- Pulsed
(Note 1)
FQD7P06
-60
-5.4
-3.42
-21.6
25
(Note 2)
(Note 1)
(Note 1)
(Note 3)
Unit
V
A
A
A
V
mJ
A
mJ
V/ns
W
W
W/°C
°C
°C
Gate-Source Voltage
Single Pulsed Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Power Dissipation (T
A
= 25°C) *
Power Dissipation (T
C
= 25°C)
90
-5.4
2.8
-7.0
2.5
28
0.22
-55 to +150
300
T
J
, T
STG
T
L
- Derate above 25°C
Operating and Storage Temperature Range
Maximum lead temperature for soldering purposes,
1/8" from case for 5 seconds
Thermal Characteristics
Symbol
R
JC
R
JA
R
JA
Parameter
Thermal Resistance, Junction-to-Case, Max.
Thermal Resistance, Junction-to-Ambient *
Thermal Resistance, Junction-to-Ambient, Max.
FQD7P06
4.5
50
110
Unit
°C/W
°C/W
°C/W
* When mounted on the minimum pad size recommended (PCB Mount)
