Heyco Nylon PCB Supports

Tension Barb Style

•

Provide spacing

between the printed

circuit board and the panel or

between circuit boards.

•

Wide, ribbed wings produce a secure

fit with extra stability.

•

Multiple spacing heights from

.187˝ (4,7 mm) to .750˝ (19,0 mm).

•

Two Styles:

1) Panel barb end, plus tension barb

end for PCB.

2) Panel barb end, plus locking

barb end for PCB.

PANEL DIMENSIONS

Maximum Mounting

Thickness

Hole

Diameter

in. mm. in. mm.

PCB DIMENSIONS

Maximum Mounting

Thickness

Hole

Diameter

in. mm. in. mm.

PART NO.

DESCRIPTION

Spacing

Natural

PART DIMENSIONS

Head

Foot

Length

mm.

in. mm.

in.

3640

3641

3642

3643

3644

3645

3646

SS T 3/16

SS T 1/4

SS T 3/8

SS T 7/16

SS T 1/2

SS T 5/8

SS T 3/4

.19

.25

.38

.44

.50

.63

.75

SS T Series

4,8

6,4

9,5

11,1

12,7

15,9

19,0

.07

1,8

.187

4,7

.06

1,6 .156 4,0

.40

10,2

.21

5,3

Standard color natural.

*Extension beyond .070˝ (1,8 mm) thick panel.

Locking Barb Style

PANEL DIMENSIONS

Maximum Mounting

Thickness

Hole

Diameter

in. mm. in. mm.

PCB DIMENSIONS

Maximum Mounting

Thickness

Hole

Diameter

in. mm. in. mm.

PART NO.

DESCRIPTION

Spacing

Natural

in.

3670

3671

3672

3673

3674

3675

3676

SS L 3/16

SS L 1/4

SS L 3/8

SS L 7/16

SS L 1/2

SS L 5/8

SS L 3/4

.19

.25

.38

.44

.50

.63

.75

PART DIMENSIONS

Head

Foot

Length

mm.

in. mm.

SS L Series

4,8

6,4

9,5

11,1

12,7

15,9

19,0

.07

1,8

.187

4,7

.06

1,6 .156 4,0

.35

8,9

.21

5,3

Standard color natural.

*Extension beyond .070˝ (1,8 mm) thick panel.

.062 (1,6 mm) Max.

PCB Thickness

.062 (1,6 mm) Max.

PCB Thickness

Mounting Hole = .156" (4,0 mm)

.070 (1,8 mm) Max.

Panel Thickness

.070 (1,8 mm) Max.

Panel Thickness

Mounting Hole = .187" (4,7 mm)

Tension Barb

Locking Barb

Quick

Specs

Material

Certifications

Flammability Rating

Temperature Range

Nylon 6/6

Recognized under the Component Program of Underwriters’

Laboratories File E197049

94V-2

32°F (0°C) to 185°F (85°C)

1-800-526-4182 • 732-286-1800 (NJ) • FAX: 732-244-8843 • www.heyco.com
