PIN
RECEPTACLES
FOR .040” - .050” DIAMETER PINS (#02 CONTACT)
FOR .040” - .060” DIAMETER PINS (#03 CONTACT)
0355
0355-0-15-XX-02-XX-10-0
Solder mount in .102 min. mounting hole
.016
.118 DIA.
.100
.100 DIA.
.260
0354
.119 DIA.
0354-0-15-XX-02-XX-10-0
.028
.100
.117
3490
.109 DIA.
.094 DIA.
KNURL
.081 DIA.
Pentagonal press-fit in .104 min. plated
through-hole
.020
3490-0-15-XX-02-XX-10-0
Press-fit in .091 mounting hole
.012
3808
3808-0-15-XX-02-XX-10-0
Press-fit in .090 mounting hole
.260
.088 DIA.
.053
.290
.088
.160
.105 DIA.
.016
.090 .095
.175
.030
.192
.290
.093 DIA.
KNURL
.081 DIA.
.039 DIA.
.059 DIA.
.108 DIA.
.120
.068 DIA.
HOLE
.020
9184
9184-0-15-XX-02-XX-40-0
Bottom entry, surface mount
.092 min. plated through-hole
Also available on carrier tape,
Order as: 9184-0-57-XX-02-XX-40-0
9222
9222-2-15-XX-02-XX-40-0
Bottom entry, surface mount
.082 min. plated through-hole
Also available on carrier tape,
Order as: 9222-2-57-XX-02-XX-40-0
Carrier tape format for
9184 and 9222.
1,500 pieces per 13” reel
12mm
.156 DIA.
.130 DIA.
.156 DIA.
.120 DIA.
.190
.160
.088
.100
.055
.200
.173
.088
8mm
.090 DIA.
.070
.080 DIA.
.125
4064
4064-0-18-XX-03-XX-40-0
Surface mount
Also available on 16mm wide carrier tape:
2,400 parts per 13” reel
Order as: 4064-0-58-XX-03-XX-40-0
.156 DIA.
.140 DIA.
.020
.162
.200
.078 DIA.
.010
.180
P.C.B. PAD
.107
.090
P.C.B. Layout
.100
.114
.180
SPECIFICATIONS:
Shell Material:
Brass Alloy 360, 1/2 Hard
Contact Material:
Beryllium Copper Alloy 172, HT
Dimensions: Inches
Tolerances On:
Lengths:
± .005
2011/65/EU
ORDER CODE: XXXX - X - XX - XX -
XX
- XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
15
10
μ”
GOLD OVER NICKEL (RoHS)
SPECIFY CONTACT FINISH:
01
200
μ”
TIN/LEAD OVER NICKEL
80
200
μ”
TIN OVER NICKEL (RoHS)
27
30
μ”
GOLD OVER NICKEL (RoHS)
Diameters: ± .002
Angles:
±2°
RoHS - 2
SELECT CONTACT:
#02 or #03
CONTACT (DATA ON PAGE 259)
(For alternate contact choices, see group F on page 248)
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
PAGE 187 | PIN RECEPTACLES
