Hex Code Table
FCXXXX
FC2098
FC2099
FC2100
FC2101
FC2102
FC2103
FC2104
FC2105
FC2106
FC2107
FC2108
FC2109
FC2110
FC2111
FC2112
FC2113
FC2114
FC2115
FC2116
FC2117
FC2118
FC2119
FC2120
FC2121
FC2122
FC2123
FC2124
FC2125
FC2126
FC2127
FC2128
FC2129
FC2130
FC2131
FC2132
FC2133
FC2134
FC2135
FC2136
FC2137
FC2138
FC2139
FC2140
FC2141
FC2142
FC2143
FC2144
FC2145
FC2146
FC2147
FC2148
Length (L
)
1/8
3/16
1/4
5/16
3/8
7/16
1/2
9/16
5/8
11/16
3/4
13/16
7/8
15/16
1
1-1/16
1-1/8
1-3/16
1-1/4
1-5/16
1-3/8
1-7/16
1-1/2
1-9/16
1-5/8
1-11/16
1-3/4
1-13/16
1-7/8
1-15/16
2
2-1/8
2-1/4
2-3/8
2-1/2
2-5/8
2-3/4
2-7/8
3
3-1/4
3-1/2
3-3/4
4
4-1/4
4-1/2
4-3/4
5
5-1/4
5-1/2
5-3/4
6
Tolerances
Unless otherwise Specified
.xxx +/-.005
.xx +/-.010
Angular +/- 1 Degree
Linear +/-.005
Break all sharp edges
THREAD
1/4 Hex Female Standoff
L
1/4
L
THREAD (TYPICAL)
Create a part number:
Length
FCXXXX
Thread
XXX
Material
XX
Finish
XX
________________
-
__________
-
__________
-
_______
Thread
Thread Code
(XXX)
440
632
832
1032
Tapped Thru
A, B, S
1
1
1
1-1/8
SS
3/4
1
1
1
Longer Parts
Blind Tap Depth
1/4
3/8
7/16
1/2
Material
Material Code (XX)
A
B
S
SS
N
Aluminum
Brass
Steel
Stainless Steel
Nylon
Aluminum (A), Brass (B), Steel (S), Stainless Steel (SS)
Compatible Finish
A, B, S, SS
B, S
A
A
A
B, S
B, S
SS
A
A
B, S. SS
B, S
0 - Plain
5 - Nickel Plate (QQ-N-290)
6 - Iridite #14 Gold (MIL-C-5541E)
7 - Iridite Clear (MIL-C-5541E)
9 - Alodine 1200
12 - Zinc Clear (ASTM-B-633)
16 - Electro Tin (MIL-T-10727 TYPE 1)
20 - Passivation (MIL-F-14072D)
22 - Clear Anodize (MIL-A-8625-TYPE2)
(Sulphuric) Hot Water Seal (Clear)
24 - Black Anodize (MIL-A-8625)
26 - Black Oxide
28 - Zinc Yellow (ASTM-B-633)
Source Control Drawing:
To be produced by
Fascomp Electronic Hardware
Fascomp Electronic Hardware
7814 Kingspointe Pkwy
Orlando, FL 32819
www.fascomp.com
Tel: (407) 226-2112
Fax: (407) 226-3370
