temp-o-gide
™
Flame Retardant Card Guides for
1
⁄
16
th
PCBs
• 25 Standard Lengths from 2"- 14" in
1
⁄
2
" increments
• Precision Molded for rigidity, strength and heat resistance from flame retardant 94V-O UL rated materials
• Stainless Steel Conductive Inserts available for all lengths
(see page 13)
Rigid, strong and economical, TEMP-O-GIDEs provide the
design flexibility and installed reliability that your most
demanding products require. Retention is firm and there are
no special tools or fixtures required for installation. Locking
ejectors can be used for positive PCB retention and inser-
tion/extraction ease
(see page 12-14 for details).
Mounting Information:
Snap-in metal plates: 0.047" - 0.090" (1.2mm - 2.3mm) thick
Hole Size: 0.172" (4.4mm) diameter + 0.003" (0.08mm) -
0.002" (0.06mm) x 0.232" (5.9mm) 1/64
th
drill
Center - 0.220" x 0.168"+ 0.003"- 0.001"
Rear - 0.235" x 0.168"+ 0.003"- 0.001"
Material Specifications:
UL Rated 94V-O, Rust colored, Flame Retardant 6/6 Nylon
Oxygen Index: +28%
UL File #E84658
Application Notes:
Slotting or elongating of the second and third mounting
hole is recommended to allow for length variations
and to provide for easier assembly.
Prolonged pre-assembly exposure to high humidity can cause
molded Nylon components to “grow” out of tolerance. Storage
in a cool dry place is recommended. Open sealed vapor barrier
bags at the time of production to assure optimum shelf life.
Recommended Mounting Holes
Temp-O-Gide
Part No.
FR-200
FR-250
FR-300
FR-350
FR-400
FR-450
FR-500
FR-550
FR-600
FR-650
FR-700
FR-750
FR-800
2" thru 8" Lengths
A
±.032 (.81)
.984 (25.0)
1.484 (37.7)
Temp-O-Gide
L
±.062 (1.6)
Part No.
FR-850
FR-900
FR-950
FR-1000
FR-1050
FR-1100
FR-1150
FR-1200
FR-1250
FR-1300
8-1/2" thru 14" Lengths
A
+.032 (.81)
-.047 (1.2)
C
+.016 (.41)
-.032 (.81)
D
±.005
(.13)
T
±.007
(.18)"
L
±.062 (1.6)
1.969 (50.0)
2.469 (62.7)
2.969 (75.4)
3.469 (88.1)
3.939 (100.0)
4.438 (112.7)
4.938 (125.4)
5.438 (138.1)
5.906 (150.0)
6.406 (162.7)
6.875 (174.6)
7.375 (187.3)
7.875 (200.0)
8.375 (212.7)
8.875 (225.4)
9.375 (238.1)
9.875 (250.8)
10.375 (263.5)
10.875 (276.2)
11.344 (288.1)
11.844 (300.8)
12.344 (313.5)
12.812 (325.4)
13.312 (338.1)
13.812 (350.8)
11.906 (302.4)
5.953 (151.2)
.093 (2.4)
.156 (4.0)
10.406 (264.3)
5.203 (132.2)
.093 (2.4)
.156 (4.0)
8.938 (227.0)
4.469 (113.5)
.078 (2.0)
.141 (3.6)
7.469 (189.7)
3.735 (94.9)
.078 (2.0)
.141 (3.6)
2.969 (75.4)
4.953 (125.8)
5.969 (151.6)
FR-1350
FR-1400
cage code (FSCM)
32559
© copyright 2004 Bivar Inc.
www.bivar.com
18
