Application areas:

♦ Scan code to pay socket

♦ Scan the QR code to pay for the washing machine

♦ Scan the QR code to pay for various recreational vehicles

♦ Scan and pay for various engineering vehicles

♦ Scan the QR code to pay at the mahjong machine

♦ Scan the QR code to pay for the air purifier

♦ Scan the QR code to pay for the massage chair

Module features :

√ Bluetooth 5.1 protocol

√ Countdown display

√ Timing voice reminder

√ Communication distance within 15 meters

product description

NY-6801-001 Bluetooth module is based on Bluetooth 5.1 version. It is small in size, equipped with display and voice driver. It is simple and convenient to develop. It is suitable for customers with R&D capabilities to add scan code payment functions to traditional devices.

After the user scans the code to pay, the D3 pin of the NY-6801-001 Bluetooth module outputs a high level. After the timer ends, the D3 pin outputs a low level. The MCU can determine whether the device needs to work through the level status of the D3 pin. It can also be made separately into a scan code payment controller to control the power on and off of the device.

Hardware parameters

2.1 Pin description

2.2 Performance parameters

Platform usage instructions

1. Account registration : Follow Pay Now official account --> Account registration
2. Bind the device: Pay the official account immediately --> Merchant login --> Bind the device and select the countdown type

(Note: Bluetooth devices need to scan the QR code on the shell or packaging bag to add the device. The payment code and the addition code are different)

1. Set the package (the package needs to be set to countdown type)
2. Scan the code to pay: After the user scans the code to pay, he needs to turn on Bluetooth and positioning, click [Start Device], the D3 pin of the Bluetooth module outputs high level, and outputs low level when the timer is over.

Reference application plan

3.1 Scan code to pay socket (applicable to devices that control 220V electricity)

3.2 Scan the QR code to pay for children’s cars (applicable to equipment that controls DC power)
