LM3856 audio amplifier

Overview

1. Function description:
This design is an audio amplifier based on the LM3856 operational amplifier;
it is equipped with an independent button to increase or decrease the volume when the self-locking switch is pressed;
2. Design features:
PCB board size is about 10cm × 10 ㎝, can be sampled at Jialichuang;
except for integrated chips and buttons, other components are basically all SMD components to save PCB space;
it uses microUSB-B for power supply.
