Based on STC microcontroller, this is a multi-functional controller for vehicle lights, door locks, etc.
Update Log:
2024/03/13 First Release (Firmware and supporting components uploaded)
Electrical Parameters :
Maximum Operating Voltage ≤ 30V DC
Maximum Load Current 5A
Action Response ≤ 10ms
Function Details:
1. Brake lights flash 3 times quickly after braking, then remain on
. 2. Rear fog lights synchronize with the above function
. 3. The above function is disabled after the fog lights are turned on, maintaining the original warning function.
4. Can be linked to control other vehicle equipment or functions; explore on your own.
Notes:
Requires some hands-on ability. Suitable
for those interested in vehicle modification . Open
Source License
: This project uses the CC-BY-NC-SA 3.0 open source license, i.e., Creative Commons Attribution-NonCommercial-ShareAlike.
CC: Creative Commons Attribution
-Attribution. You must give appropriate attribution, provide a link to this license, and indicate whether modifications were made (to the original work).
SA: Share Alike. If you remix, transform, or build upon this work, you must share and distribute your contributions under the same license as the original.
NC: Non-Commercial. You may not use this work for commercial purposes.
(Illustration)
Car headlight controller (firmware, software).zip
PDF_Car Modification - Lighting Controller.zip
Altium_Car Modification - Lighting Controller.zip
PADS_Car Modification - Lighting Controller.zip
BOM_Car Modification - Lighting Controller.xlsx
