tea2025 redraw

Overview

November 19, 2024: Thanks to the comments section for pointing out the issue. I hadn't noticed the silkscreen markings on the capacitors on the circuit board. I've now adjusted them, increased the trace width, and fine-tuned the routing.
A 5521 female connector and indicator light circuit have been added to the power supply section. The indicator light circuit is very simple and can be omitted.
The modified board has not been tested and verified; please use it with caution.
Criticism and suggestions are welcome.

Feedback adjustments have been made, and a 330Ω resistor has been added to reduce gain.
