AD9201ARSRL

Among 2 related components, AD9201ARSRL have related pdf.

Part Number	Manufacturer	Description	Datasheet
AD9201ARSRL	ADI	Analog to Digital Converters - ADC Dual CH 20MHz 10B Resolution CMOS	Download
AD9201ARSRL	Rochester Electronics	2-CH 10-BIT PROPRIETARY METHOD ADC, PARALLEL ACCESS, PDSO28, SSOP-28	Download

AD9201ARSRL parameters：

Description

2-CH 10-BIT PROPRIETARY METHOD ADC, PARALLEL ACCESS, PDSO28, SSOP-28

Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	SSOP
package instruction	SSOP,
Contacts	28
Reach Compliance Code	unknown
Maximum analog input voltage	3.25 V
Minimum analog input voltage	-0.5 V
Converter type	ADC, PROPRIETARY METHOD
JESD-30 code	R-PDSO-G28
JESD-609 code	e0
length	10.2 mm
Maximum linear error (EL)	0.2441%
Humidity sensitivity level	1
Number of analog input channels	2
Number of digits	10
Number of functions	1
Number of terminals	28
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output bit code	BINARY
Output format	PARALLEL, WORD
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	240
Sampling rate	20 MHz
Sample and hold/Track and hold	SAMPLE
Maximum seat height	2 mm
Nominal supply voltage	3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
width	5.3 mm
