AS13CV

Among 3 related components, AS13CV have related pdf.
Part Number Manufacturer Description Datasheet
AS13CV NKK Slide Switches SPDT ON-OFF-ON.150' VERT. W/BRACKET Download
AS13CV NDK Switch, SPDT, Horizontal, Through Hole-right Angle Download
AS13CV-RO NKK Slide Switches SPDT ON-OFF-ON.150' Download
AS13CV parameters:

Description

Switch, SPDT, Horizontal, Through Hole-right Angle

Parametric
Parameter NameAttribute value
Brand NameNKK Switches
Is it lead-free?Lead free
Is it Rohs certified?conform to
Reach Compliance Codecompliant
ECCN codeEAR99
Actuator angle
Actuator colorWHITE
Actuator length0.15 inch
Actuator materialGLASS FILLED POLYAMIDE
Actuator typeSLIDE
Other featuresMOUNTING BRACKET
body width5.6896 mm
body height19.0754 mm
Body length or diameter10.2108 mm
center contact materialPHOSPHOR BRONZE
Center contact platingGOLD OVER SILVER
Contact (DC) maximum rated power R load0.4VA@28VDC
Contact functionON-OFF-ON
Contact resistance0.05 mΩ
Dielectric withstand voltage500VAC V
Electrical life50000 Cycle(s)
End contact materialBRASS
End contact platingGOLD OVER NICKEL
Shell materialGLASS FILLED NYLON
Insulation resistance500000000 Ω
insulator materialCARBON COMPOSITE POLYMER
JESD-609 codee4
Installation featuresTHROUGH HOLE-RIGHT ANGLE
Number of positions3
Maximum operating temperature85 °C
Minimum operating temperature-10 °C
PCB hole count5
SolderabilityWAVE
surface mountNO
Switch actionHORIZONTAL
switch functionSPDT
Switch typeSLIDE SWITCH
Terminal surfaceGold (Au)
Terminal length0.161 inch
Terminal materialBRASS
Termination typeSOLDER
Base Number Matches1
