DS14C238WMX

Among 4 related components, DS14C238WMX have related pdf.

Part Number	Manufacturer	Description	Datasheet
DS14C238WMX	Texas Instruments	RS-232 Interface IC Single Supply TIA/EIA-232 4x4 Driver/Receiver 24-SOIC 0 to 70	Download
DS14C238WMX	National Semiconductor（TI ）	Single Supply TIA/EIA-232 4X4 Driver/Receiver	Download
DS14C238WMX/NOPB	National Semiconductor（TI ）	IC QUAD LINE TRANSCEIVER, PDSO24, M24B-24, Line Driver or Receiver	Download
DS14C238WMX/NOPB	Texas Instruments	Single Supply TIA/EIA-232 4x4 Driver/Receiver 24-SOIC 0 to 70	Download

DS14C238WMX parameters：

Description

Single Supply TIA/EIA-232 4X4 Driver/Receiver

Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	National Semiconductor（TI ）
package instruction	M24B-24
Reach Compliance Code	_compli
ECCN code	EAR99
Other features	EXTERNAL CHARGE PUMP
Differential output	NO
Number of drives	4
High level input current maximum value	0.00001 A
Input properties	SCHMITT TRIGGER
Interface integrated circuit type	LINE TRANSCEIVER
Interface standards	EIA-232-E; TIA-232-E; V.28
JESD-30 code	R-PDSO-G24
JESD-609 code	e0
length	15.4 mm
Humidity sensitivity level	3
Number of functions	4
Number of terminals	24
Maximum operating temperature	70 °C
Minimum operating temperature
Minimum output swing	10 V
Output characteristics	TOTEM-POLE
Maximum output low current	0.0032 A
Output polarity	INVERTED
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP24,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	220
power supply	5 V
Certification status	Not Qualified
Maximum receive delay	6500 ns
Number of receiver bits	4
Maximum seat height	2.65 mm
Maximum slew rate	10 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
maximum transmission delay	4000 ns
width	7.5 mm
