IRF9630STRLPBF..

Among 2 related components, IRF9630STRLPBF.. have related pdf.

Part Number	Manufacturer	Description	Datasheet
IRF9630STRLPBF	Vishay	——	Download
IRF9630STRLPBF	International Rectifier （ Infineon ）	Power Field-Effect Transistor, 6.5A I(D), 200V, 0.8ohm, 1-Element, P-Channel, Silicon, Metal-oxide Semiconductor FET, TO-263AB, TO-263, 3 PIN	Download

IRF9630STRLPBF.. parameters：

Description

Power Field-Effect Transistor, 6.5A I(D), 200V, 0.8ohm, 1-Element, P-Channel, Silicon, Metal-oxide Semiconductor FET, TO-263AB, TO-263, 3 PIN

Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	International Rectifier （ Infineon ）
Parts packaging code	D2PAK
package instruction	SMALL OUTLINE, R-PSSO-G2
Contacts	4
Reach Compliance Code	compliant
ECCN code	EAR99
Avalanche Energy Efficiency Rating (Eas)	500 mJ
Shell connection	DRAIN
Configuration	SINGLE
Minimum drain-source breakdown voltage	200 V
Maximum drain current (ID)	6.5 A
Maximum drain-source on-resistance	0.8 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JEDEC-95 code	TO-263AB
JESD-30 code	R-PSSO-G2
Number of components	1
Number of terminals	2
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	P-CHANNEL
Maximum power consumption environment	74 W
Maximum pulsed drain current (IDM)	26 A
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	SINGLE
Maximum time at peak reflow temperature	40
transistor applications	SWITCHING
Transistor component materials	SILICON
