REF102AP

Showing 4 Results for REF102AP, including REF102AP,REF102AP, etc. You can look for possible substitutions between devices by comparing the similarities and differences between them.

Part Number	Manufacturer	Description	Datasheet
REF102AP	Burr-Brown	10V Precision Voltage Reference	Download
REF102AP	Texas Instruments	2.5ppm/°C Drift, 10-V Precision Voltage Reference 8-PDIP	Download
REF102AP-BI	Burr-Brown	Voltage Reference, 10V, PDIP8,	Download
REF102APG4	Texas Instruments	2.5ppm/°C Drift, 10-V Precision Voltage Reference 8-PDIP	Download

REF102AP Related Product Datasheets：

Part Number	Datasheet
REF102AP 、 REF102APG4	Download Datasheet
REF102AP-BI	Download Datasheet
REF102AP	Download Datasheet

REF102AP Related Products：

Part Number	REF102APG4	REF102AP
Description	2.5ppm/°C Drift, 10-V Precision Voltage Reference 8-PDIP	2.5ppm/°C Drift, 10-V Precision Voltage Reference 8-PDIP
Brand Name	Texas Instruments	Texas Instruments
Is it Rohs certified?	conform to	conform to
Parts packaging code	DIP	DIP
package instruction	DIP, DIP8,.3	DIP, DIP8,.3
Contacts	8	8
Reach Compliance Code	compli	compli
ECCN code	EAR99	EAR99
Analog Integrated Circuits - Other Types	THREE TERMINAL VOLTAGE REFERENCE	THREE TERMINAL VOLTAGE REFERENCE
JESD-30 code	R-PDIP-T8	R-PDIP-T8
JESD-609 code	e4	e4
length	9.81 mm	9.81 mm
Number of functions	1	1
Output times	1	1
Number of terminals	8	8
Maximum operating temperature	85 °C	85 °C
Minimum operating temperature	-25 °C	-25 °C
Maximum output voltage	10.01 V	10.01 V
Minimum output voltage	9.99 V	9.99 V
Nominal output voltage	10 V	10 V
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	DIP
Encapsulate equivalent code	DIP8,.3	DIP8,.3
Package shape	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified
Maximum seat height	5.08 mm	3.9 mm
Maximum supply voltage (Vsup)	36 V	36 V
Minimum supply voltage (Vsup)	11.4 V	11.4 V
Nominal supply voltage (Vsup)	15 V	15 V
surface mount	NO	NO
Maximum voltage temperature coefficient	10 ppm/°C	10 ppm/°C
Temperature level	OTHER	OTHER
Terminal surface	Nickel/Palladium/Gold (Ni/Pd/Au)	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal form	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
Fine-tuning/adjustable output	YES	YES
Maximum voltage tolerance	0.1%	0.1%
width	7.62 mm	6.35 mm
Base Number Matches	1	1
