| Part Number |
S02-08-R-3CS816 |
S02-08-R-3CS926 |
S02-08-R-6CS816 |
S02-08-R-90 |
S02-08-R-90CS926 |
| Description |
solder & shield tubing s02-08-R-3cs816 |
S02-08-R-3CS926 |
S02-08-R-6CS816 |
S02-08-R-90 |
S02-08-R-90CS926 |
| Temperature identification |
- |
yes |
yes |
yes |
yes |
| Temperature identification type |
- |
Thermal discoloration |
Thermal discoloration |
Thermal discoloration |
Thermal discoloration |
| Connector type |
- |
Shield terminator |
Shield terminator |
Shield terminator |
Shield terminator |
| Pre-installed leads |
- |
yes |
yes |
yes |
yes |
| Preassembled lead types |
- |
55A0111 |
55A0111 |
55A0111 |
55A0111 |
| Lead splitting |
- |
Stranded wire |
Stranded wire |
Stranded wire |
Stranded wire |
| Lead plating materials |
- |
tin |
tin |
tin |
tin |
| Lead color |
- |
orange color |
blue |
white/black |
white/black |
| Termination method |
- |
welding |
welding |
welding |
welding |
| Insulating sleeve outer diameter |
- |
4.3 mm [ .17 in ] |
4.3 mm [ .17 in ] |
4.3 mm [ .17 in ] |
4.3 mm [ .17 in ] |
| Expand inner diameter (minimum value) |
- |
4.3 mm [ .17 in ] |
4.3 mm [ .17 in ] |
4.3 mm [ .17 in ] |
4.3 mm [ .17 in ] |
| Recovered inner diameter (maximum value) |
- |
2.15 mm [ .085 in ] |
2.15 mm [ .085 in ] |
2.15 mm [ .085 in ] |
2.15 mm [ .085 in ] |
| total length |
- |
16.5 mm [ .65 in ] |
16.5 mm [ .65 in ] |
16.5 mm [ .65 in ] |
16.5 mm [ .65 in ] |
| Preassembled lead size (mm²) |
- |
.38 |
.38 |
.38 |
.38 |
| Preassembled lead size (AWG) |
- |
22 |
22 |
22 |
22 |
| Shield outer diameter (minimum value) |
- |
2.15 mm [ .085 in ] |
2.15 mm [ .085 in ] |
2.15 mm [ .085 in ] |
2.15 mm [ .085 in ] |
| Dielectric outer diameter (maximum) |
- |
1.25 mm [ .05 in ] |
1.25 mm [ .05 in ] |
1.25 mm [ .05 in ] |
1.25 mm [ .05 in ] |
| Preassembled Lead Dimensions (CMA) |
- |
754 |
754 |
754 |
754 |
| Resistance properties |
- |
Immersion protection |
Immersion protection |
Immersion protection |
Immersion protection |
| Wire temperature (max) (°C) |
- |
105 |
105 |
105 |
105 |
| MIL/NAS specifications (MIL-S-83519, NAS-1747) |
- |
AS83519/2 |
AS83519/2 |
AS83519/2 |
AS83519/2 |
| Meet government qualifications |
- |
yes |
yes |
yes |
yes |
